Поз.
Артикул
Описание
11
PIN
44
SHOCK ABSORBER
47
SPACER TUBE FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
50
RUBBER BUFFER
50
RUBBER BUFFER
53
RETAINER
56
RETAINER
59
HEXAGON NUT BRACKET TO SIDE MEMBER M14 X 1,5
62
SPRING CASE
65
RUBBER SPRING
68
SCREW CLAMPING BOLT TO ALTERNATOR M 12X1,5X60
71
NUT BRACKET TO SIDE MEMBER M12X1.5
77
SUPPORT FRONT
80
SUPPORT REAR
83
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
86
NUT SUPPORT TO FRAME
89
HEXAGON HEAD BOLT AT FRAME, REAR M16X1.5X40
92
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE M16X1.5
95
SUPPORT AIR SPRING BELLOWS,BOTTOM
95
SUPPORT FRONT AXLE AIR SPRING BELLOWS
98
AIR SPRING BELLOWS TRAILING AXLE LIFT
98
AIR SPRING BELLOWS REAR AXLE
98
AIR SPRING BELLOWSBL121
101
PLATE ,WEB 629012 13 520210,WEB 629015 13 520032
104
NUT POWER CYLINDER TO BRACKET
104
NUTM24X1.5
131
U-BOLT
134
SPRING SADDLE RIGHT
134
SPRING SADDLE LEFT
137
GASKET
140
NUT AIR-SPRING-BELLOWS SUPPORT TO REAR AXLE
143
PLATE
146
ECCENTRIC SCREW ROCKER PANEL TO BRACKET M8X12
149
152
999
