Поз.
Артикул
Описание
11
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
19
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
19
LINE FROM OIL TANK TO HOSE
19
LINE , Replaced By: A0004291601
27
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
27
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
35
LINE FROM PUMP TO HIGH PRESSURE HOSE
35
TUBE FROM HIGH PRESSURE HOSE TO STEERING
43
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
43
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
43
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
43
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
43
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
43
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
51
LINE FROM HIGH PRESSURE HOSE TO STEERING
51
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
59
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
59
LINE , Replaced By: A0005516256
67
HOSE DELIVERY LINE TO STEERING
67
HOSE RETURN, FROM STEERING TO OIL TANK
75
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
83
FITTING DELIVERY LINE TO PUMP
91
SCREW-IN FITTING DELIVERY LINE TO PUMP
99
SCREW CONNECTION RETURN, FROM STEERING TO OIL TANK
99
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
107
BRACKET DELIVERY AND SUCTION LINES TO FRAME
115
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
115
CLAMP LINE MOUNTING
115
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
123
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
123
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
123
CLAMP DELIVERY AND SUCTION LINES TO FRAME
131
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
131
CLAMP HOSE TO FITTING AND TO OIL TANK
131
CLAMP , Replaced By: N000000000667
