Поз.
Артикул
Описание
5
SHIFT LEVER
8
BUSHING PAWL TO ROD END,5 443047
11
BOOT SHIFT LEVER
17
KNOB (SHIFT LEVER HANDLE), TO BE ADAPTED DURING ASSEMBLY
26
NUT , Replaced By: N308673010000
26
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
29
COVER
35
JOINT BEARING SHIFT LEVER BEARING,K040603
35
JOINT BEARING SHIFT LEVER BEARING,K040603
38
LOCK RING SHIFT LEVER BEARING
41
PIN SHIFT LEVER BEARING,K040603
44
BOOT SHIFT LEVER BEARING
47
BRACKET SHIFT LEVER UPPER PART,K040603
50
BRACKET SHIFT LEVER LOWER PART,K040603
53
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
53
NUT , Replaced By: N913004008001
53
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
56
BUSHING SHIFT LEVER BEARING TO CAB FLOOR
59
COVERING BOOT TO CAB
59
COVERING BOOT TO CAB
62
SCREW COVERING
65
COVER COVERING TO CAB
74
BRACKET SHIFT LEVER BEARING TO CAB FLOOR
77
SHEET METAL SCREW BRACKET TO CAB
83
RUBBER PAD SHIFT LEVER TO CAB FLOOR,K040603
86
TUBE. BUSHING CAB FLOOR COVERING
89
RUBBER PAD SHIFT LEVER BEARING TO CAB FLOOR
92
BRACKET SHIFT LEVER BEARING TO CAB FLOOR
95
SCREW SUPPORT TO FENDER
95
SCREW , Replaced By: N304017008018
227
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
227
HOSE , Replaced By: A0009872827
230
FITTING (PARTS KIT),LINE RUPTURE
233
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
236
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
239
CONNECTOR RELEASE BEARING LUBRICATION
239
CONNECTOR , Replaced By: A0019904078
242
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
245
SCREW CONNECTOR TO TRANSMISSION
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
INSULATION CAB/TRANSMISSION COMPRESSED-AIR-LINE SEPARATION POINT
999
CONNECTOR REAR SHIFTING ROD TO CONNECTOR
999
BUSHING COMPRESSED AIR LINE THRU CAB FLOOR,K040603
999
PIN SHIFT LEVER BEARING,K 040604
999
BRACKET SHIFT LEVER LOWER PART,K 040604
999
BRACKET SHIFT LEVER UPPER PART,K 040604
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
EXPANSION PLUG ROD END
999
SCREW , Replaced By: N000933008337
999
SCREW , Replaced By: A0099900101
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
