Поз.
Артикул
Описание
5
CONNECTOR FROM CONNECTOR TO EXHAUST MUFFLER
8
BRACKET TAIL PIPE
11
BRACKET BRACKET TO CROSS CONNECTION STRUT
14
BRACKET BRACKET TO CROSS CONNECTION STRUT
17
SCREW BRACKET TO SIDE MEMBER
17
SCREW , Replaced By: N304017010002
20
NUT STRAP TO BRACKET
20
NUT , Replaced By: N910113010000
23
END PIECE BEHIND CAB,UPWARD
23
END PIECE , Replaced By: A6524926714
26
FLAP (RAIN DEFLECTOR)
29
PROTECTIVE PLATE (HEAT SHIELD)
32
PROTECTIVE PLATE (HEAT SHIELD)
35
BASE PLATE HEAT SHIELD TO TAILPIPE
38
CLAMP , Replaced By: A4374920440
38
CLAMP HEAT SHIELD TO TAILPIPE
41
SCREW , Replaced By: N304017008021
41
SCREW PIPE CLAMP
44
SCREW BRACKET TO CROSS CONNECTION STRUT
44
SCREW , Replaced By: N304017008034
47
NUT , Replaced By: N913004008001
47
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
PROTECTIVE PLATE (HEAT SHIELD)
53
SCREW BRACKET TO SIDE MEMBER
53
SCREW , Replaced By: N304017010002
56
NUT , Replaced By: N910113010000
56
NUT STRAP TO BRACKET
59
CLAMP EXHAUST PIPE TO BRACKET
62
SCREW BRACKET TO SIDE MEMBER
62
SCREW , Replaced By: N304017010002
65
NUT , Replaced By: N910113010000
65
NUT STRAP TO BRACKET
68
BRACKET TAIL PIPE
71
SCREW BRACKET TO CROSS CONNECTION STRUT
71
SCREW , Replaced By: N304017008034
74
NUT , Replaced By: N913004008001
74
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
77
BRACKET (STRUT),FROM TAIL PIPE TO SIDE MEMBER
80
SCREW , Replaced By: N304017010002
80
SCREW BRACKET TO SIDE MEMBER
83
NUT , Replaced By: N910113010000
83
NUT STRAP TO BRACKET
86
CLAMP EXHAUST PIPE TO BRACKET
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
END PIECE EXHAUST MUFFLER,LEFT REAR
999
REAR EXHAUST PIPE TAIL PIPE,FRONT
999
END PIECE
999
BRACKET , Replaced By: A6524921441
999
PROTECTIVE PLATE (HEAT SHIELD) 1380 MM
999
EXHAUST MUFFLER
999
BRACKET TAIL PIPE
999
END PIECE
999
END PIECE
999
REAR EXHAUST PIPE
999
END PIECE REAR EXHAUST PIPE,5 758826
999
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
CLAMP , Replaced By: N071555090502
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
NUT CHECK VALVE TO AIR RESERVOIR
