Поз.
Артикул
Описание
74
WHEEL BRAKE CYLINDER TRISTOP CYLINDER BOSCH 20/30
74
WHEEL BRAKE CYLINDER TRISTOP CYLINDER KNORR 20/30, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
74
WHEEL BRAKE CYLINDER TRISTOP CYLINDER WABCO 20/30, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
77
YOKETO 008 420 95 18,008 420 97 18,BOSCH
78
SEAL RINGKNORR
80
DIAPHRAGMTO 008 420 95 18,008 420 97 18,BOSCH
80
DIAPHRAGM , Replaced By: A0004314128
80
DIAPHRAGM , Replaced By: A0004314128
80
DIAPHRAGMTO 008 420 61 18,009 420 22 18
80
DIAPHRAGMTO 007 420 68 18,69 18,70 18,WABCO
81
SEAL RING , Replaced By: A0099979748
81
SEAL RINGKNORR
81
SEAL RINGKNORR
82
PLUGTO 009 420 22 18,008 420 20 18
83
CUPTO 007 420 68 18,WABCO
86
REPAIR KIT TRISTOP CYLINDER TO 008 420 95 18, 008 420 97 18, BOSCH
86
REPAIR KIT DIAPHRAGM PART TO 007 420 68 18, WABCO
89
REPAIR KIT TRISTOP CYLINDER TO 009 420 22 18, KNORR
92
REPAIR KIT SPRING LOAD ACCUMULATOR CYLINDER TO 008 420 20 18,KNORR
92
REPAIR KIT SPRING LOAD ACCUMULATOR PART TO 007 420 68 18,007 420 70 18,WABCO
95
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
95
NUT COMBINATION CYLINDER TO BEARING BRACKET
101
BEARING BRACKET WHEEL CYLINDER
104
SCREW , Replaced By: N308676016013
104
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
113
BRAKE ANCHOR TRISTOP CYLINDER
116
SCREW , Replaced By: N910105014010
116
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
116
SCREW BRACKET TO SIDE MEMBER M 14X55,5 543914
119
NUT , Replaced By: N910113014001
119
NUT BRACKET TO SIDE MEMBER
122
BRACKET BRACKET TO SUPPORT
125
SCREW , Replaced By: N304017008021
125
SCREW PIPE CLAMP
128
NUT , Replaced By: N913004008001
128
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
128
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
131
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
134
WASHER , Replaced By: N000433015005
134
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
137
COTTER PIN STRAP TO SUPPORT
140
T-FITTING COMBINATION CYLINDER,CONNECTION: "12"
140
T-FITTING COMBINATION CYLINDER,CONNECTION: "12"
143
T-FITTING TRISTOP CYLINDER,CONNECTION: "11"
149
T-FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "21,22"
152
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
155
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
158
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
161
SCREW. UNION SCREW LINE CONNECTION
