Поз.
Артикул
Описание
168
AXLE STOP AXLE STOP TO FRAME
168
STOP AXLE STOP TO FRAME
170
RUBBER BUFFER SWINGING LINK
172
NUT STRAP TO BRACKET
172
NUT , Replaced By: N910113010000
175
SCREW BRACKET TO SIDE MEMBER M 12X40
182
NUT SUPPORT TO SIDE MEMBER
189
BRACKET MOUNTING BRACKET
196
SCREW BRACKET TO CROSS MEMBER
196
SCREW BEARING BRACKET TO CROSS MEMBER
203
FITTED SCREW BRACKET TO CROSS MEMBER
210
WASHER SENSOR CABLE TO REAR AXLE,LEFT AND RIGHT
217
NUT BRACKET TO CROSS MEMBER
217
NUT BEARING BRACKET TO CROSS MEMBER
224
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE
224
NUT , Replaced By: N913023016001
238
PIN LIFT ARM
245
WASHER PISTON ROD TO LIFTING ARM
252
COTTER PIN PISTON ROD TO LIFTING ARM
259
PIN PISTON ROD TO LIFTING ARM
259
PIN CYLINDRICAL TUBE TO CROSS MEMBER
262
CYLINDER
262
CYLINDER
266
BOOT PISTON ROD
273
SEAL RING PISTON ROD
280
HOUSING
280
HOUSING
287
SEAL RING PISTON ROD
294
BOOT PISTON ROD
301
SEAL RING PISTON ROD
308
BEARING PISTON ROD
315
GREASE NIPPLE
315
GREASE NIPPLE PROTECTIVE TUBE
315
GREASE NIPPLE , Replaced By: N071412010100
999
SHACKLE LEFT
999
SHACKLE RIGHT
999
COVER SWITCH BOX
999
SEAL RING PRESSURE SWITCH
999
PIPE SOLENOID VALVE
999
NUT PRESSURE SWITCH
999
T-FITTING PRESSURE SWITCH
999
BRACKET OIL LINE MOUNTING
999
HYDRAULIC UNIT
999
BRACKET HYDRAULIC LINES TO FRAME
999
ANGLE BATTERY CABLE TO SIDE MEMBER, NOT USED
999
SWITCH (PRESSURE SWITCH) 70 BAR
