Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
5
ACCELERATOR PEDAL
8
JOINT
11
SCREW ACCELERATOR PEDAL TO FLOOR PLATE
14
STOP FULL THROTTLE
17
LEVER (PEDAL LEVER)
20
LOCK PLATE
23
BUSHING ,B 892893
26
LEVER (CONTROL LEVER)
29
BALL PIVOT INTERMEDIATE LEVER
32
LEVER (CONTROL LEVER)
35
SCREW WIRE CABLE TO LEVER
38
BUSHING WIRE CABLE TO LEVER
41
WASHER WIRE CABLE TO LEVER
44
NUT PUMP TO BRACKET
47
LOCK RING. RETAINING RING ACCELERATOR PEDAL TO LEVER
50
SCREW BRACKET TO FRAME
53
WASHER PLUG SOCKET TO BRACKET
56
NUT PUMP TO BRACKET
59
62
BALL SOCKET PULL ROD TO LEVER
65
NUT
68
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
