Поз.
Артикул
Описание
5
DISTRIBUTOR BRAKE LINE TO BRAKE MASTER CYLINDER
5
DISTRIBUTOR MASTER CYLINDER,FRONT
5
BANJO UNION , Replaced By: A0004286324
8
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
11
SEAL RING FUEL LINE TO FEED PUMP
14
LINE FROM ADAPTER FITTING TO DISTRIBUTOR,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
14
LINE FROM DISTRIBUTOR TO LEFT WHEEL BRAKE CYLINDER 1165 MM
17
LINE FROM ADAPTER FITTING TO DISTRIBUTOR,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
17
LINE FROM DISTRIBUTOR TO REAR RIGHT BRAKE HOSE
20
GROMMET
23
BRAKE HOSE FRONT LEFT AND RIGHT
23
BRAKE HOSE BETWEEN THE LINES,730280
26
LOCK , Replaced By: A0004280673
26
RETAINING SPRING BRAKE HOSE TO BRACKET
29
BRACKET ADDITIONAL CABLE HARNESS TO WHEELHOUSE PANEL
29
BRACKET BRAKE HOSE
32
LINE TO RIGHT FRONT WHEEL, 000,001,010 UP TO CHASSIS 107476,100,101,110 UP TO CHASSIS 179099
35
LINE FROM ADAPTER FITTING TO DISTRIBUTOR,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
35
LINE FROM BRAKE MASTER CYLINDER TO DISTRIBUTOR, 055235
35
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
38
VALVE , Replaced By: A1214290134
38
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0004313907
38
VALVE , Replaced By: A0004313907
39
BRACKET VALVE TO BRACKET
40
BRACKET LINE MOUNTING,5 7245845 801938
40
BRACKET , Replaced By: A6674290540
40
BRACKET , Replaced By: A6674290640
41
SCREW STRUT TO CROSS MEMBER M 10X25
42
NUT CROSS MEMBER TO SIDE MEMBERS
44
LINE FROM BRAKE POWER REGULATOR TO RIGHT FRONT WHEEL 2000 MM
44
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
47
ADAPTER FITTING BETWEEN THE LINES
50
DISTRIBUTOR AT SIDE MEMBER,745033 N 000001 P 000001
50
DISTRIBUTOR AT SIDE MEMBER,745033 N 000001 P 000001
53
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
53
SCREW BRACKET TO CROSS CONNECTION STRUT
56
NUT STRAP TO BRACKET
57
WASHER
57
WASHER BRACKET TO SIDE MEMBER
59
LINE FROM SPRING LOAD ACCUMULATOR TO RIGHT DISTRIBUTOR
59
LINE FROM DISTRIBUTOR TO REAR HEIGHT CONTROL VALVE
62
BRAKE HOSE BRAKE LINE TOWARDS DISTRIBUTOR
65
RETAINING SPRING BRAKE HOSE TO BRACKET
65
LOCK , Replaced By: A0004280673
68
DISTRIBUTOR
68
DISTRIBUTOR REAR AXLE
74
WASHER SWITCH TO FIRE WALL
74
WASHER FROM SLAVE CYLINDER TO HOSE,895778
80
NUT HEATING PIPE TO BRACKET
83
LINE FROM DISTRIBUTOR TO LEFT WHEEL BRAKE CYLINDER 1165 MM
86
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
89
BRACKET BRAKE LINE TO FIRE WALL
89
BRACKET BRAKE LINE TO FIRE WALL
89
BRACKET , 811451 N 000000 P 000000, Replaced By: A6674280840
92
BRACKET RELEASE SPRING,625235
95
CLAMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.F 076976, Replaced By: A1244760940
95
CLAMP FRONT CROSS MEMBER
98
CLIP BRAKE LINE TO CAB SUBSTRUCTURE,D 047756
101
CLIP BRAKE LINE TO CAB SIDE MEMBER
104
BRACKET , Replaced By: A6884287440
107
BRACKET BRAKE HOSE TO SIDE MEMBER,762132 N 000000 P 000000
110
BRACKET BRAKE HOSE TO FRAME
110
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 813314 N 000000 P 000000, Replaced By: A6674230723
110
BRACKET BRAKE HOSE TO SIDE MEMBER
110
BRACKET , Replaced By: A6704230323
113
SCREW BRACKET TO CONSOLE
116
NUT CROSS MEMBER TO SIDE MEMBERS
119
BRACKET OIL LINES
119
CLAMP. EXTENDABLE SPACER BREATHER LINE
122
CLAMP ELECTRIC CABLE TO BRAKE HOSE
122
CLAMP. EXTENDABLE SPACER BREATHER LINE
122
BRACKET OIL LINES
125
BRACKET OIL LINES
125
CLAMP. EXTENDABLE SPACER BREATHER LINE
125
CLAMP ELECTRIC CABLE TO BRAKE HOSE
128
DOUBLE CLAMP. CLAMP CABLE HARNESS MOUNTING,P 217441
131
CLAMP BRAKE LINE TO SIDE MEMBER
134
LOOM TIE LINE MOUNTING 280 MM
134
LOOM TIE LINE MOUNTING
137
NUT HEATING PIPE TO BRACKET
