Поз.
Артикул
Описание
5
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET,5 509582
5
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET,5 509581
8
SCREW OIL FILLER NECK TO BRACKET,5 458408
11
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
14
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET
17
CLAMP HOSE TO FIRE WALL
20
SHEET METAL SCREW
20
SHEET METAL SCREW , Replaced By: N007981003214
23
BRACKET COOLING WATER LINE TO FIRE WALL
26
CLAMP FEED LINE TO THERMOSTAT
29
SHEET METAL SCREW BRACKET TO CAB
32
BRACKET HOSE TO FIRE WALL
35
SHEET METAL SCREW BRACKET TO CAB,5 906887
38
BRACKET HOSE TO FIRE WALL
38
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6735010620
41
SHEET METAL SCREW BRACKET TO FIRE WALL 6.3X22
44
WASHER COVER PLATE TO COVER PLATE
47
BRACKET DE-AERATION LINE, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
47
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6745060140
50
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
53
CLAMP CABLE HARNESS MOUNTING
53
CLAMP , Replaced By: N000000001045
53
CLAMP , Replaced By: N916016010211
56
CLAMP BRAKE HOSE BRACKET
59
SCREW BRACKET TO CROSS CONNECTION STRUT
59
SCREW , Replaced By: N304017008034
59
SCREW OIL LINE TO CRANKCASE
62
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
65
NUT PUMP TO BRACKET
65
NUT , Replaced By: N913004006001
68
PIPE SOCKET (HEATING LINE),FROM ENGINE TO HEATER
68
PIPE SOCKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3662001056
71
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
71
GASKET , Replaced By: A3662030380
74
HOSE (HEATING LINE),FROM ENGINE TO HEATER
77
PIPE (HEATING LINE),FROM ENGINE TO HEATER
80
HOSE (HEATING LINE),FROM ENGINE TO HEATER
83
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
83
CLAMP , Replaced By: N000000000667
86
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
86
CLAMP HOSE TO FITTING AND TO OIL TANK
89
HOSE (HEATING LINE) FROM EXPANSION TANK TO HEATER
92
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
92
CLAMP HOSE TO FITTING AND TO OIL TANK
95
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
95
CLAMP , Replaced By: N000000000667
999
SHIM COOLING WATER HOSE TO OIL FILLER PIPE BRACKET,5 306211
999
RIVET COOLANT LINE ON FAN SHROUD
