Поз.
Артикул
Описание
5
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET,5 509582
5
BRACKET COOLING WATER HOSE TO OIL FILLER PIPE BRACKET,5 509581
8
SCREW OIL FILLER NECK TO BRACKET,5 458408
17
CLAMP HOSE TO FIRE WALL
20
SHEET METAL SCREW
20
SHEET METAL SCREW , Replaced By: N007981003214
23
BRACKET COOLING WATER LINE TO FIRE WALL
26
CLAMP FEED LINE TO THERMOSTAT
29
SHEET METAL SCREW COVER PLATE TO COVER PLATE
32
BRACKET HOSE TO FIRE WALL
35
SHEET METAL SCREW BRACKET TO CAB,5 906887
38
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6735010620
38
BRACKET HOSE TO FIRE WALL
41
SHEET METAL SCREW BRACKET TO FIRE WALL 6.3X22
44
WASHER COVER PLATE TO COVER PLATE
47
BRACKET COOLING WATER HOSES
50
BRACKET COOLING WATER HOSES
53
BRACKET COOLING WATER LINE TO SUCTION PIPE,5 270331
56
BRACKET DE-AERATION LINE
59
SCREW , Replaced By: N304017008021
59
SCREW PIPE CLAMP
62
WASHER EXHAUST MUFFLER TO STRAP
62
WASHER , Replaced By: N000125008443
65
CLAMP CABLE HARNESS MOUNTING
65
CLAMP , Replaced By: N000000001045
65
CLAMP , Replaced By: N916016010211
65
CLAMP BRAKE HOSE BRACKET
68
SCREW CLAMP MOUNTING M 6X16
68
SCREW , Replaced By: N000000001146
71
NUT PUMP TO BRACKET
71
NUT , Replaced By: N913004006001
74
PIPE SOCKET (HEATING LINE),FROM ENGINE TO HEATER,5 270331
74
PIPE SOCKET AT ENGINE
77
GASKET , Replaced By: A3662030380
77
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
80
HOSE (HEATING LINE),FROM ENGINE TO HEATER
80
HOSE (HEATING LINE),FROM ENGINE TO HEATER,5 270331
83
PIPE (HEATING LINE),FROM ENGINE TO HEATER
86
HOSE (HEATING LINE),FROM ENGINE TO HEATER
89
CLAMP , Replaced By: N000000000667
89
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
92
CLAMP HOSE TO FITTING AND TO OIL TANK
92
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
95
HOSE (HEATING LINE) FROM EXPANSION TANK TO HEATER
98
CLAMP HOSE TO FITTING AND TO OIL TANK
98
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
101
CLAMP , Replaced By: N000000000667
101
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
RUBBER RING
