Поз.
Артикул
Описание
50
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
50
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
50
TEST CONNECTION
50
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
50
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
53
BRACKET TEST CONNECTION, TO BE ADAPTED DURING ASSEMBLY
56
ADAPTER FITTING TEST CONNECTION
57
ELBOW FITTING HOSE WIDTH, 6 MM,TO M 22
58
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
59
GUIDE SIGN AIR SPRING BELLOWS,LEFT AND RIGHT
62
GUIDE SIGN SUPPLY
65
VALVE (OVERFLOW VALVE) WABCO
65
VALVE (OVERFLOW VALVE) GRAU
66
VALVE (OVERFLOW VALVE) WABCO
66
VALVE (OVERFLOW VALVE) GRAU
68
DIAPHRAGM
68
DIAPHRAGM
71
FITTING LINE CONNECTION
72
FITTING SHUTTLE VALVE,CONNECTION: "20"
74
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
77
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
80
SCREW. UNION SCREW LINE CONNECTION
83
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
86
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
86
THRUST RING CHECK VALVE TO AIR RESERVOIR
89
O-RING CHECK VALVE TO AIR RESERVOIR
92
NUT CHECK VALVE TO AIR RESERVOIR
95
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
98
VALVE PRESSURE LIMITER FOR BELLOWS RESIDUAL PRESSURE
101
REPAIR KITWABCO
999
PULL ROD PNEUMATIC SUSPENSION CONTROL
999
NUT BALL SOCKET TO ROD
999
NUT
999
VALVE
999
REPAIR KITTO 001 429 52 44
999
BALL JOINT LEFT-HAND THREAD,BALL DIAMETER 10 MM
999
BALL JOINT TRAVEL SENSOR
