Поз.
Артикул
Описание
5
BRAKE LEVER , NO.8650I.......I.......I I II
8
HANDLE , NO.8650I.......I.......I I II .......INO.9985I.......I I II
11
COVERING , NO.8650I.......I.......I I II .......INO.9985I.......I I II
14
COVERING , NO.8650I.......I.......I I II .......INO.9985I.......I I II
14
COVERING , NO.8316I.......I.......I I II .......I.......INO.7C52I I II
17
CONSOLE
17
CONSOLE
17
CONSOLE
20
SCREW CONSOLE TO CAB M 10X80
23
SCREW , Replaced By: N304017010002
26
WASHER CONSOLE TO CAB
29
STOP BUFFER. DAMPING RING
32
SCREW CROSS MEMBER TO SIDE MEMBERS
35
WASHER GROUND CABLE
35
WASHER GROUND CABLE
38
NUT BRAKE LEVER TO CONSOLE
38
NUT BRAKE LEVER TO CONSOLE
41
COVERING AT CONSOLE, NO.8650I.......I.......I I II .......INO.9985I.......I I II
41
COVERING AT CONSOLE, NO.8650I.......I.......I I II .......INO.9985I.......I I II
44
TREENAIL FUSE BOX
47
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
50
BRAKE CABLE FRONT LEFT
50
BRAKE CABLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.B 969878, Replaced By: A6884207485
50
BRAKE CABLE FRONT LEFT
53
BRAKE CABLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.B 969878, Replaced By: A6884207585
53
BRAKE CABLE FRONT RIGHT
53
BRAKE CABLE FRONT RIGHT
59
GROMMET
62
SPRING BRAKE CABLE
65
PIN BRAKE CABLE TO BRAKE LEVER
68
NUT BRAKE CABLE TO BRAKE LEVER
71
BRACKET FUEL LINE TO SIDE MEMBER
71
BRACKET , Replaced By: A3184280240
74
BRACKET TO ENGINE
86
SCREW PLUG SOCKET TO FRAME
93
NUT HORN TO BRACKET M8
110
GUIDE PLATE REAR BRAKE CABLE TO BRACKET
113
SCREW PARKING BRAKE VALVE TO INSTRUMENT PANEL,TB108828
116
LOCK WASHER RAIL TO BATTERY SUPPORT
119
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
119
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
125
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
125
SCREW CABLE TO ALTERNATOR
128
WASHER PLUG SOCKET TO BRACKET
131
LOCK WASHER CABLE TO FUSE BOX
140
SCREW , Replaced By: N914146006102
146
CLAMP BATTERY CABLE TO BRACKET
146
CLAMP BRAKE HOSE BRACKET
149
SCREW CLAMP TO BRACKET
152
NUT PUMP TO BRACKET
155
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
155
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
158
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
167
BRACKET
170
LOOM TIE AIR INTAKE HOSE TO CLAMP
170
LOOM TIE , Replaced By: A3459977390
173
GROMMET LINE THRU LEFT SIDE MEMBER
