Поз.
Артикул
Описание
5
FRONT SPRING ,D 078172
5
FRONT SPRING ,D 078172
5
FRONT SPRING 7-LEAF
8
SPRING LEAFN0.1
8
SPRING LEAFNO.1,B 831781
11
SPRING LEAFN0.2
11
SPRING LEAFNO.2,B 831781
14
SPRING LEAFNO.3, TO 688 320 71 02, 72 02
14
SPRING LEAFN0.3
14
SPRING LEAFNO.3,B 831781
17
SPRING LEAFNO.4
17
SPRING LEAFN0.4
19
SPRING LEAFN0.5
20
SPRING LEAFN0.6
20
SPRING LEAFNO.6
23
SPRING LEAFNO.7
24
SPACER
26
SPRING BOLTAM 10X105
26
SPRING BOLTM10X115
29
NUT SPRING BOLT
32
SHIM REAR SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
35
SPACER TUBE , Replaced By: A0003213253
38
SCREW SPRING CLAMP TO SPRING LEAF NO.4,NO.7,M 8X95
41
NUT SPRING CLAMP TO SPRING LEAF
44
RUBBER MOUNTING REAR SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
53
SPACER TUBE SPRING SHACKLE TO SPRING REAR BRACKET 22 / 12,5 MM
56
WASHER REAR SPRING & SPRING SHACKLE TO REAR SPRING BRACKET
59
NUT , Replaced By: N910113018004
62
SCREW CONSOLE TO SUPPORT M 12X120
65
NUT BRACKET TO SIDE MEMBER M12X1.5
68
SHACKLE FRONT SPRING TO FRONT-SPRING REAR BRACKET
71
PLATE FRONT SPRINGS TO FRONT AXLE
74
U-BOLT FRONT SPRINGS TO FRONT AXLE M14X1,5X160 MM
77
NUT BRACKET TO BATTERY CASE
999
SPACER
