Поз.
Артикул
Описание
8
BRACKET LINE MOUNTING, TO BE ADAPTED DURING ASSEMBLY
8
BRACKET , Replaced By: A6985013820
11
BRACKET MOUNTING USED FOR COMPRESSED AIR LINES
11
BRACKET LINE MOUNTING
11
BRACKET LINE MOUNTING, TO BE ADAPTED DURING ASSEMBLY
17
BRACKET BULKHEAD SCREW CONNECTION
20
BRACKET BULKHEAD SCREW CONNECTION
23
BRACKET BULKHEAD SCREW CONNECTION
29
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
29
CLAMP , Replaced By: N000000000667
32
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
32
CLAMP OIL DIPSTICK TO RADIATOR
35
SCREW PUMP TO BRACKET
35
SCREW , Replaced By: N304017006016
35
SCREW , Replaced By: N304017008034
35
SCREW , Replaced By: N304017008021
38
WASHER , Replaced By: N000125008443
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
44
NUT , Replaced By: N913004008001
50
LOOM TIE LINE MOUNTING
53
INSULATING HOSE37 MM, ORDER BY THE METER
56
BRAKE HOSE CENTRAL AXLE
59
NUT BRACKET TO SIDE MEMBER
62
FITTING DELIVERY LINE TO FRAME
65
FITTING , Replaced By: A0009907871
71
T-FITTING RELAY VALVE,CONNECTION: "20"
74
FITTING DELIVERY LINE TO PUMP
77
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
80
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
83
BRACKET REAR AXLE BRAKE HOSE
86
SCREW , Replaced By: N304017008034
89
NUT , Replaced By: N913004008001
101
HOSE AIR COMPRESSOR CONNECTION 240 MM, ORDER BY THE METER
104
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
104
CLAMP , Replaced By: N000000000667
107
TEST CONNECTION
107
TEST CONNECTION
107
TEST CONNECTION
113
FITTING HYDRAULIC LINE TO BRACKET,K 130132
116
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
BRAKE HOSE FROM AIR COMPRESSOR TO PRESSURE REGULATOR
999
