Поз.
Артикул
Описание
35
BUSHING , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
44
BUSHING , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
47
BUSHING
59
EXPANSION PLUG
71
GUIDE PIN SHIFT CASE,4750584 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
74
PLUG CASE COVER
98
GASKET , Replaced By: A3812610280
98
GASKET , Replaced By: A3812610880
98
GASKET SHIFT CASE,TOP,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
98
GASKET TRANSMISSION CASE TOP COVER
101
SCREW SHIFTING CYLINDER TO CASE
101
SCREW , NOT USED
104
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
104
SPRING WASHER , Replaced By: N000137008212
155
WOODRUFF KEY FLANGE TO SHIFTING TUBE
158
LOCK PLATE SHIFTING ROD
158
LOCK PLATE SHIFTING ROD, 004101
161
NUT , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817
161
NUT , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
224
PLATE , FROM TRANSMISSION
224
PLATE , Replaced By: A3452600046
227
WASHER DETENT PLATE TO COVER, UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
230
SPRING WASHER SHIFTING CYLINDER TO YOKE
233
NUT , FROM TRANSMISSION
236
INTERLOCK PIN ,A 057455, 341.023,027,032,034,036,038,041,042,043,044,045 FROM IDENT NO. A 057456 SEE SPARE PARTS LIST 713.0, MF 859A 077314, 341.116 FROM IDENT NO. A 077315 SEE SPARE PARTS LIST 713.0, MF 859
239
THRUST PIECE
241
SPRING CASE COVER,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
265
PLUG CASE COVER,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
352
SCREW COVER PLATE TO BRACKET
358
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
358
SPRING WASHER , Replaced By: N000137008212
364
BREATHER TRANSFER CASE
