Поз.
Артикул
Описание
5
AIR CLEANER COMPRESSED AIR LINE
8
FILTER ELEMENT
11
SEAL RINGWABCO 000 0,36.2X3.0 MM
11
SEAL RING39.2X3.0 MM
14
REPAIR KITWABCO 000 0
20
NUT CHECK VALVE TO AIR RESERVOIR
20
NUT BRACKET TO SIDE MEMBER
23
T-FITTING
29
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
32
O-RING CHECK VALVE TO AIR RESERVOIR
35
FITTING BETWEEN THE LINES
41
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
44
REPAIR KITTO 001 431 30 06
56
FITTING DELIVERY LINE TO PUMP
62
ELBOW FITTING AIR RESERVOIR I
65
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "23"
67
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
67
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
69
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
70
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "10"
71
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
72
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
74
SEAL RING LINE CONNECTION
77
WASHER
80
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
83
NUT CHECK VALVE TO AIR RESERVOIR
86
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
89
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
92
O-RING CHECK VALVE TO AIR RESERVOIR
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
98
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
101
VALVE SEAT RINGWABCO,5 433388
104
BUSHINGWABCO,5 433388
105
LOCK RINGWABCO,5 433388
107
T-FITTING BETWEEN THE LINES
111
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
113
O-RING CHECK VALVE TO AIR RESERVOIR
116
NUT CHECK VALVE TO AIR RESERVOIR
122
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
128
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
131
SEAL RINGTO 006 997 00 72
140
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
143
SEAL RINGTO 006 997 00 72
143
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
999
FITTING FITTING TO SUBSTRUCTURE
999
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
