Поз.
Артикул
Описание
5
HOSE FROM RADIATOR TO THERMOSTAT
8
CLAMP HOSE 70-90X13 MM
8
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
8
CLAMP , Replaced By: A0059972990
8
CLAMP , Replaced By: N000000000674
11
PIPE ELBOW AT WATER PUMP,5 1935955 510517
11
PIPE ELBOW AT WATER PUMP,5 510518
12
PIPE ELBOW FOR SCREW FITTING
14
SCREW BRACKET TO FRAME SIDE MEMBER
15
PIN PIPE ELBOW TO BRACKET,K 023462
16
SPACER RING PIPE ELBOW TO BRACKET,K 023462
16
WASHER , Replaced By: A1894660751
17
NUT STRAP TO BRACKET
17
NUT , Replaced By: N910113010000
20
HOSE FROM RADIATOR OUTLET TO WATER PUMP
23
CLAMP HOSE 70-90X13 MM
23
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
23
CLAMP , Replaced By: A0059972990
23
CLAMP , Replaced By: N000000000674
26
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
29
CONNECTOR FOR SCREW FITTING
32
GASKET CONNECTOR
32
GASKET CONNECTOR, Replaced By: A0002011280
32
GASKET CONNECTOR, Replaced By: A0002011180
32
GASKET CONNECTOR, Replaced By: A0002011080
35
SCREW END PIECE TO EXHAUST PIPE M 10X25
35
SCREW
35
SCREW , Replaced By: N304017010051
38
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
38
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
39
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
40
LINE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
40
LINE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
41
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
44
HOSE DE-AERATION PIPE TO EXPANSION TANK
47
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
50
GASKET. SEAL DE-AERATION PIPE TO ENGINE
53
SCREW END PIECE TO EXHAUST PIPE M 10X25
56
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
56
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
56
CLAMP , Replaced By: N000000000667
59
CLAMP
59
CLAMP
59
CLAMP , Replaced By: N000000000670
