Поз.
Артикул
Описание
5
VALVE
8
BRACKET 3/2-WAY VALVE, N 000000 P 083147
11
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
14
SPACER TUBE BRACKET TO FRAME SIDE MEMBER
17
WASHER EXHAUST MUFFLER TO STRAP
20
NUT STRAP TO BRACKET
23
SCREW COVER PLATE TO COVER PLATE M 6 X 12
26
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
29
POWER CYLINDER EXHAUST BRAKE
32
SCREW CABLE HARNESS MOUNTING
35
SPRING WASHER , Replaced By: N000137008212
35
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
38
BALL SOCKET ROD TO BALL PIVOT
38
BALL SOCKET ROD TO BALL PIVOT
41
NUT , Replaced By: N304035008001
41
NUT
44
SECURING CLIP. CIRCLIP
47
LEVER P.T.O. CONTROL
47
LEVER , Replaced By: A6672600837
50
BALL PIVOT
53
CLAMPING SLEEVE LEVER TO SHIFTING SHAFT
56
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
56
PLASTIC PIPE AERATION, ORDER BY THE METER
59
FITTING , Replaced By: A0029905971
59
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
59
FITTING (PARTS KIT),LINE RUPTURE
62
HOSE (3/2-WAY SOLENOID VALVE) "3"
62
HOSE 3/2-WAY VALVE,CONNECTIONS: "1","2"
62
HOSE VACUUM LINE
65
HOSE P.T.O. CONTROL VALVE
68
GROMMET LINE MOUNTING 16/11 MM
68
GROMMET LINE TO CROSS MEMBER
71
CLAMP LINE MOUNTING
74
TAPPING SCREW BREATHER PIPE TO CROSS MEMBER, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 002464
999
GASKET CASE PART I TO CASE PART II
999
VALVE
999
PISTON
999
VALVE CHECK VALVE
999
SEAL RING
999
GASKET CONNECTION FLANGE
999
CLAMP
999
CLAMP
999
HYDRAULIC PUMP SERVICE WITH DUMPING PLATFORM TYPE 234/2
999
SCREW PLUG
999
LOOM TIE LINE MOUNTING 280 MM
999
SEAL RING
999
HOSE , Replaced By: A1170780281
999
HOSE
999
HOSE FROM 3/2-WAY VALVE TO POWER CYLINDER, N 000001 P 149402
999
SPACER TUBE CLAMP ON BRACKET
999
VALVE BELOW INSTRUMENT PANEL
999
BRACKET 3/2-WAY VALVE, N 000001 P 083148
999
BALL10 MM
999
SEAL RING LINE CONNECTION
999
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
999
SCREW , Replaced By: N304014008001
