Поз.
Артикул
Описание
260
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
300
RESERVOIR COMPRESSED AIR 30 L, TO VOSS 232,5 9363665 812731 FOR VEHICLES WITH VOSS 230 CONNECTOR: ADD. MOUNT FITTING "A 004 997 82 72" WITH O-RING "A 000 987 04 46" AND THRUST RING "A 000 997 02 03" TO AIR RESERVOIR
300
RESERVOIR30L,276 MM,8.5 BAR
300
RESERVOIR , Replaced By: A0054322201, +002A0009870446, +002A0009940203, +002A0049978272
300
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0034322101
300
RESERVOIR ,5 9363655 812730, Replaced By: A0034320301, +001A0009970834, +001A0059977672
300
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0024320801
300
RESERVOIR COMPRESSED AIR 4 L,EURO,5 9363665 812731
305
STRAP AIR RESERVOIR
310
BRACKET AIR RESERVOIR
310
BRACKET , Replaced By: A6764320240
315
BASE AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
317
SCREW BRACKET TO LEFT SIDE MEMBER M 10X1X30
318
HEXAGON NUT
320
SCREW , Replaced By: N304017008021
320
SCREW PIPE CLAMP
322
WASHER , Replaced By: N000125008443
322
WASHER EXHAUST MUFFLER TO STRAP
325
NUT , Replaced By: N913004008001
325
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
328
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
330
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
332
FITTING LINE CONNECTION
332
FITTING AIR RESERVOIR,CONNECTION: "26", NOT USED
335
HOLLOW SCREW HEATING CONNECTION
345
SEAL RING LINE CONNECTION
349
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
353
SCREW. UNION SCREW LINE CONNECTION
353
SCREW. UNION SCREW LINE CONNECTION
353
SCREW. UNION SCREW , Replaced By: A0009973734
360
SCREW PLUG , Replaced By: N000908022011
360
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
375
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
375
THRUST RING CHECK VALVE TO AIR RESERVOIR
375
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
390
O-RING CHECK VALVE TO AIR RESERVOIR
405
BRACKET AIR RESERVOIR,5 9363655 812730
420
STRAP , Replaced By: A6734301140
420
STRAP AIR RESERVOIR TO BRACKET
435
SCREW END PIECE TO EXHAUST PIPE M 10X25
440
SCREW , Replaced By: N304017010002
440
SCREW BRACKET TO SIDE MEMBER
450
WASHER RADIATOR TO RUBBER MOUNTING
450
WASHER , Replaced By: N000125010532
465
NUT , Replaced By: N910113010000
465
NUT STRAP TO BRACKET
470
SCREW CONSOLE TO SIDE MEMBER
470
SCREW BRACKET TO SIDE MEMBER
470
SCREW PIPE CLAMP
470
SCREW CROSS MEMBER TO FRAME M 10X30
470
SCREW , Replaced By: N304017010002
470
SCREW , Replaced By: N304017008021
470
SCREW END PIECE TO EXHAUST PIPE M 10X25
470
SCREW BRACKET TO TORSION BAR,4 9511495 554754
475
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
475
WASHER , Replaced By: N009021008213
475
WASHER , Replaced By: N006902011102
475
WASHER , Replaced By: N006902011100
475
WASHER BRACKET TO FRAME
475
WASHER BRACKET TO LEFT SIDE MEMBER
476
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
476
NUT END PIECE TO EXHAUST PIPE
476
NUT STRAP TO BRACKET
476
NUT , Replaced By: N910113010000
476
NUT , Replaced By: N913004008001
478
WASHER , Replaced By: A3609902340
478
WASHER BRACKET TO LEFT SIDE MEMBER
480
GROMMET LINE THRU LEFT SIDE MEMBER
999
BANJO UNION HEATING CONNECTION,K 169122
999
HOLLOW SCREW , Replaced By: N915036010108
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
NUT , Replaced By: N913004008001
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
SCREW VALVE TO BRACKET M 8X55
999
SCREW PUMP TO BRACKET
999
SCREW VALVE TO BRACKET
999
SEAL RING FUEL LINE TO FEED PUMP
999
SCREW , Replaced By: N304017006016
999
SCREW , Replaced By: N304017008043
999
SCREW VALVE TO BRACKET, Replaced By: N304014008002
999
BRACKET 3/2-WAY VALVE TO BRACKET,5 9363655 812730
999
SUPPORT FLUID RESERVOIR,5 287295SCHRAUBANSCHLUSS
999
BRACKET FLUID RESERVOIR,5 936365
999
BRACKET , Replaced By: A6764320240
999
BRACKET SOLENOID VALVE
999
SEAL RINGKNORR
999
SEAL RING , Replaced By: A0179978148
999
SEAL RING , Replaced By: A0005480870
999
SEAL RINGWABCO
999
FITTING LINE CONNECTION
999
VALVE (3/2-WAY SOLENOID VALVE) EKS
999
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
999
VALVE , Replaced By: A0049975736
999
VALVE (3/2-WAY SOLENOID VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
GASKET KITKNORR
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION,K 186868
999
VALVE (PRESSURE LIMIT VALVE)
999
SEAL HOLDER SEAL RINGS KNORR
999
GASKET KIT SEAL RINGS KNORR,5 937586
999
FITTING AIR RESERVOIR,CONNECTIONS: "10,20"
999
RESERVOIR ,5 934167, Replaced By: A0034320301
999
RESERVOIR , Replaced By: A0034322001
999
RESERVOIR ,5 9363655 812730, Replaced By: A0034320301, +001A0009970834, +001A0059977672
999
RESERVOIR , Replaced By: A0024311602, +001A0004317833
999
PROTECTIVE CAPWABCO
999
SCREW. UNION SCREW , Replaced By: A0009973734
999
HEATER , Replaced By: A0005480670
999
HEATER , Replaced By: A0005480870
999
ANTI-FREEZE DEVICEWABCO
999
AIR DEHYDRATOR"WABCO",5 9363665 812731
999
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
999
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
999
ADAPTER FITTING FLUID RESERVOIR TO BRACKET
