Поз.
Артикул
Описание
5
GROMMET BATTERY CABLE TO BATTERY MASTER SWITCH
8
GROMMET FOR PASSAGE OF LINE
11
INSULATING HOSE PRESSURE REGULATOR,CONNECTION "3", ORDER BY THE METER5 148812
14
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
14
EDGE GUARD SECTION SEAT, Replaced By: A0019872272
17
BRACKET BREATHER LINE TO SIDE MEMBER
20
SCREW BRACKET TO CROSS CONNECTION STRUT
20
SCREW , Replaced By: N304017008034
23
NUT , Replaced By: N913004008001
26
BRACKET COMPRESSED AIR LINE TO CAB
29
SHEET METAL SCREW BRACKET TO CAB
32
SPRING WASHER LICENSE PLATE TO BRACKET
35
BRACKET CABLE HARNESS
35
BRACKET LEFT
38
SCREW END PIECE TO EXHAUST PIPE M 10X25
41
NUT STRAP TO BRACKET
41
NUT , Replaced By: N910113010000
44
BRACKET LINE MOUNTING
47
SCREW , Replaced By: N308676012026
50
WASHER BRACKET TO FRAME
53
NUT SUPPORT TO SIDE MEMBER
56
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
56
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
59
SCREW , Replaced By: N304017008039
59
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
62
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
65
BRACKET COMPRESSED AIR LINE
68
SCREW , Replaced By: N304017010002
68
SCREW BRACKET TO SIDE MEMBER
74
NUT STRAP TO BRACKET
74
NUT , Replaced By: N910113010000
77
LOOM TIE
80
LOOM TIE LINE MOUNTING 280 MM
80
LOOM TIE LINE MOUNTING
83
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
86
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
86
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
89
CONNECTOR HOSE WIDTH, 9 MM, TO M 22
89
CONNECTOR HOSE WIDTH, 9 MM, TO M 22
95
LOCK REAR AXLE BRAKE HOSE,K 181360
98
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
98
CLAMP HOSE TO FITTING AND TO OIL TANK
101
NUT BRACKET TO SIDE MEMBER
101
NUT BRACKET TO SIDE MEMBER
104
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
104
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
104
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
104
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
104
TEST CONNECTION
107
PLUG
110
TEST CONNECTION SHUTTLE VALVE,CONNECTION: "2"
110
TEST CONNECTION SHUTTLE VALVE,CONNECTION: "2"
113
SEAL RING LINE CONNECTION
999
CLAMP BRAKE HOSE
999
HOSE COMPRESSED AIR GUIDE, REAR AXLE. 220 MM
999
CLAMP BRAKE HOSE
