Поз.
Артикул
Описание
5
MOTOR. RECIRCULATING PUMP
5
PUMP , Replaced By: A0005062999
8
HOSE (HEATING LINE),FROM ENGINE TO HEATER
11
HOSE (HEATING LINE),FROM ENGINE TO HEATER
14
CLAMP , Replaced By: N000000000667
14
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
17
BRACKET COOLING WATER LINE TO FIRE WALL
20
SHEET METAL SCREW BRACKET TO CAB
20
SHEET METAL SCREW COVER PLATE TO COVER PLATE
23
CLAMP HOSE FASTENING 50-70X13 MM
23
CLAMP , Replaced By: N000000000672
26
CLAMP FEED LINE TO THERMOSTAT
29
PIPE LINES TO BRACKET
32
SCREENING LINES TO BRACKET
32
SCREENING , Replaced By: A6738360033
999
ADHESIVE TAPE , Replaced By: A0039898585
999
ADHESIVE TAPE ELECTRIC CABLE
999
ADHESIVE TAPE PIPING
999
BRACKET COOLING WATER LINE TO FIRE WALL
