Поз.
Артикул
Описание
5
FRONT SPRING 8-LEAF
8
SPRING LEAFNO.1,4 669737
11
BUSHING
11
BUSHING
14
SPRING LEAFNO.2
17
SPRING LEAFNO.3,4 8119265 184441
17
SPRING LEAFNO.3,5 184442
20
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY
23
RIVET AT SPRING LEAF NO.7
26
SPRING LEAFNO.4
29
SPRING CLAMP , Replaced By: A3123240633
29
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY
35
RIVET AT SPRING LEAF NO.7
50
SPRING BOLT
53
NUT , Replaced By: N910113012005
59
PLATE FRONT SPRINGS TO FRONT AXLE
65
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
65
U-BOLT FRONT SPRINGS TO FRONT AXLE 260 MM
68
WASHER FRONT SPRINGS TO FRONT AXLE
71
NUT , Replaced By: N000934018001
71
NUT FRONT SPRINGS WITH TORSION BAR TO FRONT AXLE
74
SHACKLE FRONT SPRING REAR BRACKET
77
BUSHING
77
BUSHING
80
SHACKLE PIN PARTS KIT
83
GREASE NIPPLE
86
GREASE NIPPLE PROTECTIVE TUBE
89
WASHER AS REQUIRED 4.20 MM
89
WASHER AS REQUIRED 4.00 MM
92
SEAL RING SPRING SUSPENSION
95
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
98
WASHER GROUND CABLE
101
NUT , Replaced By: N910113010000
104
RUBBER MOUNTING AXLE STOP
107
SCREW END PIECE TO EXHAUST PIPE M 10X25
107
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
110
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
113
NUT , Replaced By: N910113010000
116
BRACKET RUBBER SPRING
119
SCREW , Replaced By: A9429901304
119
SCREW , Replaced By: N308676014012
122
WASHER , Replaced By: N000125015019
122
WASHER , Replaced By: N000125015019
125
NUT , Replaced By: N910113014000
125
NUT , Replaced By: N910113014000
128
RUBBER SPRING SPRING STOP TO FRAME BOTTOM SIDE
131
WASHER
134
LOCK WASHER RUBBER SPRING TO BRACKET
