Поз.
Артикул
Описание
5
TANK , Replaced By: A0004664502
8
TANK OIL
11
PIPETO 000 466 38 02
14
OIL DIPSTICK , Replaced By: A0004660867
17
COVERTO 000 466 38 02
20
FILLER CAP
23
SEAL RINGTO 000 466 38 02
26
SEAL RING
29
FILTER CARRIERTO 000 466 38 02
32
BRACKET
35
FILTER
38
SEAL RINGTO 000 466 38 02
41
CONNECTORTO 000 466 38 02
44
NUT , Replaced By: A3259900562
47
CENTERING RINGTO 000 466 38 02
50
WASHER , Replaced By: A9402680552
53
SPACER TUBETO 000 466 38 02
56
COVER PLATETO 000 466 38 02
59
RUBBER SLEEVETO 000 466 38 02
62
BRACKET OIL TANK
65
SCREW , Replaced By: N304017010028
68
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
71
SCREW VALVE TO BRACKET,5 465030
74
NUT , Replaced By: N913002006009
77
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
77
HOSE , Replaced By: A3859971582
80
LOOM TIE HOSE TO HEATING PIPE
83
LINE FROM OIL TANK TO HOSE
86
LINE FROM HOSE TO POWER STEERING PUMP
89
UNION NUT LINE CONNECTION, Replaced By: N000000006243
92
GLAND , Replaced By: A0019901267
95
FITTING SUCTION LINE TO OIL PUMP
98
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
101
LINE FROM PUMP TO HIGH PRESSURE HOSE
104
UNION NUT LINE CONNECTION, Replaced By: N000000006239
107
GLAND , Replaced By: A0019901967
110
FITTING DELIVERY LINE TO PUMP
113
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
113
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
113
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
116
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
119
UNION NUT LINE CONNECTION, Replaced By: N000000006239
122
GLAND , Replaced By: A0019901967
125
FITTING DELIVERY LINE TO PUMP
131
FITTING RETURN LINE TO STEERING
143
HOSE RETURN, FROM STEERING TO OIL TANK
146
LOOM TIE HOSE TO HEATING PIPE
149
BRACKET DELIVERY AND SUCTION LINES TO FRAME
158
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
161
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
164
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
167
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
170
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
173
SCREW DELIVERY AND SUCTION LINES TO BRACKET
176
NUT , Replaced By: N913004006001
