Поз.
Артикул
Описание
5
11
SCREW TRANSMISSION TO ENGINE M 10X50
11
SCREW-AND-WASHER ASSEMBLY TRANSMISSION TO ENGINEM10X45
11
COMBINATION BOLT TRANSMISSION TO ENGINE M10X45
14
KNOB GEARSHIFT LEVER UPPER PART, NO.8650I.......I I I II .......INO.9985I I I II I
20
VALVE (SHIFT LEVER VALVE) TO 388 267 71 10, DARK-BROWN NO.8650I.......I I I II .......INO.9985I I I II I
20
VALVE (SHIFT LEVER VALVE)
23
NUT , Replaced By: N910113010002
24
WASHER GROUND CABLE
26
27
COVERING , NO.8650I.......I I I II .......INO.9985I I I II I
29
BOOT BOTTOM
32
PLASTIC TUBE2X4MM, ORDER BY THE METER
35
UNION NUT LINE MOUNTING, Replaced By: N000000006521
38
GLAND LINE MOUNTING
41
SLEEVE LINE MOUNTING
86
FITTING LINE CONNECTION
86
FITTING QUICK-RELEASE VALVE
89
THRUST RING LOCKING VALVE
89
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
89
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
89
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
89
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
92
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
92
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
95
SCREW. UNION SCREW , Replaced By: A0009973734
98
SEAL RING , Replaced By: A0009940747
101
LOCK , Replaced By: A0009945448
104
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
104
LOOM TIE ELECTRIC CABLE MOUNTING
107
INSULATING HOSE BLUE
107
INSULATING HOSE COLOR CODE YELLOW, ORDER BY THE METER
