Поз.
Артикул
Описание
11
11
11
17
20
FUEL GAUGE DASH UNITTO A 695 470 00 01/01 03
22
FUEL FILLER CAPTO A 979 470 01 03,D 287970
23
SEAL RINGTO A 695 470 00 01/01 03
35
SEAL RING
44
FITTING
53
SUPPORT FUEL TANK
59
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
59
HEXAGON HEAD BOLT. SCREW CONSOLE TO FRAME END PLATE M14X1.5X40
59
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X50
62
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
65
WASHER BATTERY CASE
65
WASHER , Replaced By: A3859900440
68
BASE
77
STRAP FUEL TANK TO SUPPORT
83
SHIM BRAKE ANCHOR
89
PAD FUEL TANK TO CONSOLE
92
PIN STRAP TO CONSOLE
92
PIN STRAP TO CONSOLE
95
COTTER PIN STRAP TO SUPPORT
98
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
