Поз.
Артикул
Описание
5
PLATE ACCELERATOR PEDAL
10
GUARD PLATE ACCELERATOR PEDAL BEARING
15
BEARING TUBE ACCELERATOR PEDAL CONTROL,GB718835
15
BEARING TUBE ACCELERATOR PEDAL CONTROL
20
SCREW
25
LOCK WASHER
30
LEVER , INAPPLICABLE TO SUPERCHARGING SYSTEMGB718835
35
BALL PIVOT , Replaced By: A3129910120
35
BALL PIVOT LEVER
40
WASHER CLUTCH LINING WEAR INDICATOR
45
LOCK WASHER
50
NUT LEVER TO SHIFTING SHAFT
55
PULL ROD
60
PULL ROD
65
NUT BALL PIVOT TO LEVER
70
BALL SOCKET FROM CONTROL LEVER TO INTERMEDIATE BEARING
75
SNAP RING SPRING-LOADED PUSH ROD
80
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
85
SHAFT
90
BALL PIVOT , Replaced By: A3129910120
95
SPACER TUBE VIBRATION ABSORBER TO BRACKET 39 MM, TO BE ADAPTED DURING ASSEMBLY
95
SPACER TUBE , Replaced By: A3210720053
100
LEVER
105
BUSHING
110
SCREW
115
WASHER , 000855
120
HEX. NUT M 4 DIN 934-5 S. NUT FUEL CONSUMPTION DISPLAY
125
LEVER ACCELERATOR CONTROL
130
BALL PIVOT , Replaced By: A3129910120
130
BALL PIVOT LEVER
135
SCREW
140
NUT BALL PIVOT TO LEVER
145
PULL ROD
145
ROD , Replaced By: N900331006024
150
NUT BALL PIVOT TO LEVER
155
BALL SOCKET AT CONTROL LEVER
160
SNAP RING SPRING-LOADED PUSH ROD
165
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
170
BALL PIVOT ACCELERATOR PEDAL,4 859026
170
BALL PIVOT
175
BRACKET
180
SPRING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6769930010
185
LEVER
190
SCREW CONNECTOR TO TRANSMISSION
195
KNOB
200
TUBETO 323 300 00 07
205
WIRETO 323 300 00 07
210
KNOB WITH SPINDLE AND WIRE CABLE
210
NUT , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
215
CLAMP WIRE CABLE TO CAB, ON VEHICLES HAVING NO EXHAUST BRAKE
220
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
225
LOCK WASHER CLAMP TO BRACKET
230
NUT BALL PIVOT TO LEVER
235
SCREWM 6X12
240
LOCK WASHER CLAMP TO BRACKET
999
PART NAME MISSING , Replaced By: N071805010202
999
BRACKET CLUTCH PEDAL RELEASE SPRING, WITH DIESEL ENGINE WITH OM 312, OR OM 321, ENGINE
999
PEDAL PLATE , Replaced By: A3523000802
999
KNOB , Replaced By: A3413007207
999
999
KNOB , Replaced By: A3413007207
999
BALL PIVOT
