Поз.
Артикул
Описание
5
RESERVOIR AIR RESERVOIRS I AND II 40 L
5
RESERVOIR
8
RESERVOIR ,1B 883558
8
RESERVOIR AIR RESERVOIR III 20 L
11
CONSOLE AIR RESERVOIR
14
CONSOLE AIR RESERVOIR
17
STRAP AIR RESERVOIR TO CONSOLE
20
STRAP AIR RESERVOIR TO FRAME SIDE MEMBER
23
NUT BRACKET TO RETARDER
26
PIN STRAP TO CONSOLE 20 L
29
COTTER PIN STRAP TO BRACKET
32
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
35
SCREW , Replaced By: N304017010040
38
WASHER GROUND CABLE
41
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
44
BRACKET
47
SCREW BEARING BRACKET TO SIDE MEMBER
50
NUT BRACKET TO LEFT SIDE MEMBER
53
WASHER SUPPORT TO FRAME,D 127794
56
SCREW FUEL LINE TO SIDE MEMBER
59
NUT BRACKET TO LEFT SIDE MEMBER
62
PAD AT CROSS MEMBER
62
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
62
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
65
VALVE DRAIN 20 L
77
VALVE AT OUTSIDE AIR RESERVOIR
77
VALVE
77
VALVE. DRAIN VALVE DRAIN
77
VALVE
77
VALVE DRAIN, Replaced By: A0004322107
77
VALVE DRAIN, Replaced By: A0004322407
80
VALVE REPAIR KIT TO 384 432 72 07
83
FITTING LOCKING VALVE
83
FITTING LOCKING VALVE,CONNECTION: "2"
86
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
89
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
92
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
98
FITTING VALVE TO VALVE
101
VALVE (CHECK VALVE)
101
VALVE (CHECK VALVE)
101
VALVE (CHECK VALVE)
