Поз.
Артикул
Описание
41
SCREW BRACKET TO CAB REAR PANEL M 8X20
71
BRACKET LINE MOUNTING
74
SCREW SHIFT LEVER TO BRACKET M8X30
77
NUT HORN TO BRACKET M8
83
BRACKET TRANSMISSION GEARSHIFT
86
SCREW , Replaced By: N910143008002
89
NUT HORN TO BRACKET M8
95
95
BRACKET OIL LINE
96
BRACKET AT RIGHT SIDE MEMBER
98
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
98
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
101
NUT , Replaced By: N913023010002
101
HEXAGON NUT STARTING MOTOR TERMINAL 31
101
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
110
BRACKET AT CROSS MEMBER
113
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
113
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
116
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
124
BRACKET BRACKET TO LEFT SIDE MEMBER
126
128
BRACKET AT RIGHT SIDE MEMBER
129
BRACKET AT RIGHT SIDE MEMBER
132
134
BRACKET BATTERY CABLE
140
BRACKET BATTERY CABLE MOUNTING
140
BRACKET , Replaced By: A3812950440
140
BRACKET PIPING
143
145
SCREW BRACKET AND CLAMP M6X20
146
SCREW , Replaced By: N910143008002
158
NUT HORN TO BRACKET M8
158
NUT BRACKET TO FIRE WALL
