Поз.
Артикул
Описание
10
TS BRAKE BOOSTER
20
SEALING PLUGS VACUUM LINE AT BRAKE BOOSTER
30
GASKET BRAKE BOOSTER TO BEARING BRACKET
50
PIN BRAKE UNIT TO PEDAL ASSEMBLY
100
TS MASTER BRAKE CYLINDER , A 02295520080930809
110
STOP PLUG EXPANSION RESERVOIR TO MASTER CYLINDER
120
SEAL RING
130
FUSE PENDELUM SUPPORT TO BRAKE UNIT
150
EXPANSION RESERVOIR
160
COVER
180
BOLT EXPANSION RESERVOIR TO MASTER CYLINDER
200
VACUUM LINE FROM INTAKE MANIFOLD TO BRAKE BOOSTER ASSEMBLY
200
VACUUM LINE FROM INTAKE MANIFOLD TO BRAKE BOOSTER ASSEMBLY
210
VALVE
210
VALVE BRAKE BOOSTER ASSEMBLY
220
GROMMET PARTITION WALL PASSAGE
230
CLUTCH. COUPLING
230
CLUTCH VACUUM LINE
250
CLAMP
280
LINE HOLDER ENGINE HOOD HINGE,LEFT
290
SPACER RING SPACING OF FUEL LINES
