Поз.
Артикул
Описание
43
LINE FROM OIL PUMP TO HIGH PRESSURE HOSE,12005921
43
LINE FROM OIL PUMP TO HIGH PRESSURE HOSE,12005920
45
UNION NUT LINE CONNECTION
47
GLAND LINE CONNECTION
49
HOSE FROM PUMP TO STEERING
49
HOSE , Replaced By: A3059971082
49
HOSE FROM PUMP TO STEERING
49
HOSE ,12005921
49
HOSE FROM PUMP TO STEERING
49
HOSE ,300325
49
HOSE ,300325
55
LINE FROM HIGH PRESSURE HOSE TO CONNECTION FITTING,13024472
55
LINE FROM HIGH PRESSURE HOSE TO CONNECTION FITTING,1200592113024471
55
LINE FROM HIGH PRESSURE HOSE TO CONNECTION FITTING,12005920
57
UNION NUT LINE CONNECTION
59
GLAND LINE CONNECTION
61
CONNECTION FITTING FEED LINE TO STEERING
64
LINE FROM CONNECTOR I TO CONNECTOR II
69
UNION NUT LINE CONNECTION
72
GLAND LINE CONNECTION
75
CONNECTION FITTING FEED LINE TO STEERING
80
LINE FROM CONNECTOR II TO CONNECTOR III
82
UNION NUT LINE CONNECTION
83
GLAND LINE CONNECTION
84
CONNECTION FITTING FEED LINE TO STEERING
86
LINE FROM CONNECTION FITTING III TO CONNECTION FITTING IV
93
LINE FROM CONNECTION FITTING IV TO HYDRAULIC STEERING 15X1.5 MM,300326
93
LINE ,13003601
94
UNION NUT LINE CONNECTION
95
GLAND LINE CONNECTION
96
SEAL RING HIGH PRESSURE LINE TO STEERING, 341.250 FROM CHASSIS A 002104
97
SCREW-IN FITTING RETURN LINE TO STEERING
98
BANJO UNION LOW PRESSURE OIL LINE TO HYDRAULIC STEERING, 341.250 FROM CHASSIS A 002104
99
HOLLOW SCREW
100
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
106
LINE FROM STEERING TO CONNECTOR I
111
UNION NUT LINE CONNECTION, Replaced By: N000000006243
114
GLAND , Replaced By: A0019901267
117
UNION NUT
121
SEAL CONE FROM HYDRAULIC STEERING TO CONNECTION FITTING I, 341.250 FROM CHASSIS A 002104
126
CONNECTION FITTING
131
LINE FROM CONNECTION I TO CONNECTOR III
139
LINE FROM CONNECTOR II TO CONNECTOR III
145
LINE FROM CONNECTOR III TO CONNECTOR IV
153
LINE FROM CONNECTOR IV TO OIL TANK
153
LINE FROM CONNECTOR IV TO OIL TANK, FROM CHASSIS 1300360212005920
153
LINE FROM CONNECTOR IV TO OIL TANK,13003601
154
UNION NUT LINE CONNECTION, Replaced By: N000000006243
155
GLAND , Replaced By: A0019901267
156
CONNECTION FITTING
158
OIL TANK , 341.250 FROM CHASSIS A 002104
163
BRACKETTO 345 466 70 02
163
BRACKET , Replaced By: A0004660640
167
LOCK WASHER TRAILER PLUG SOCKET TO SUPPORT
171
NUT INTERMEDIATE SPEED STOP
175
SEAL RING
175
SEAL RING , Replaced By: A0099970145
179
SEAL RINGTO 000 466 38 02
179
SEAL RING , Replaced By: A0059970848
183
STRUT
183
REINFORCEMENT , Replaced By: A0004660095
187
FITTING , 993034
187
FITTING , Replaced By: A0004660571
191
FILTER SUPPORT
191
FILTER CARRIERTO 000 466 38 02
196
CONNECTOR ,12068000, 344.030,031,032,03312009117, 345.001,002,003,300
201
FILTER ELEMENT ,D 441028D 523393
201
FILTER , Replaced By: A0004660604
205
CENTERING RINGTO 000 466 38 02
209
RUBBER SLEEVETO 000 466 38 02
214
SPACER TUBETO 000 466 38 02
219
WASHER , Replaced By: A9402680552
225
SEAL RINGTO 000 466 38 02
229
COVER
229
COVER , Replaced By: A0004664405
233
OIL DIPSTICK
240
NUT , Replaced By: A3259900562
245
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
251
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
257
SCREW BRACKET TO SIDE MEMBER
263
LOCK WASHER , Replaced By: N912004010102
271
LINE , FROM CHASSIS 1300360212005920
271
LINE ,13003601
278
LINE FROM OIL TANK TO PUMP,12005921
278
HOSE
278
HOSE , Replaced By: A3859971582
278
HOSE , Replaced By: A3609970982
280
CLAMP HOSE TO OIL TANK AND TO SUCTION LINE
280
LOOM TIE HOSE TO HEATING PIPE
283
CLAMP HOSE TO INTAKE PIPE
283
CLAMP
287
HOSE
287
HOSE
289
SCREW PLUG SOCKET TO FRAME
290
LOCK WASHER RAIL TO BATTERY SUPPORT
291
NUT LEVER TO SHIFTING SHAFT
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING ON DRIVE END
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING , TO 341 460 10 01,344 460 17 01,384 460 71 01,390 460 70 01
999
SEAL RING31X3 MM
999
SEAL RING , Replaced By: A0169979048
999
SEAL RING , TO 344 460 17 01
999
SEAL RING , Replaced By: A0149976948
999
SEAL RING , Replaced By: A0079979748
999
SEAL RING , Replaced By: A0149976848
999
NEEDLE BEARING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
NEEDLE BEARING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 009 997 14 48, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING , TO 344 460 17 01
999
SEAL RING
999
OIL TANK , Replaced By: A3214600883
999
STEERING SUPPORT , Replaced By: A3444610240
999
999
999
999
999
DRAG LINK REAR
999
DRAG LINK FRONT, 341.250 FROM CHASSIS A 002104
999
999
999
VALVE BREATHER
999
BOOT BLEEDER VALVE
999
REPAIR KIT , Replaced By: A0004602161
999
REPAIR KIT , Replaced By: A0004602261
999
SEAL RING , Replaced By: A0129976048
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING , Replaced By: A0099978748
999
SEAL RING , Replaced By: A0169979148
999
SEAL RING , Replaced By: A0169978948
999
SEAL RING
999
SEAL RING , Replaced By: A0049978548
999
SEAL RING , Replaced By: A0129976148
999
SEAL RING , Replaced By: A0129975948
999
SEAL RING , Replaced By: A0089979447
999
SEAL RING
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
LOCK
999
LOCK
999
NEEDLE BEARING
999
SPACER WASHER AS REQUIRED 3.275 MM
999
SPACER WASHER AS REQUIRED 3.250 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.225 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.200 MM
999
SPACER WASHER AS REQUIRED 3.175 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.150 MM
999
SPACER WASHER AS REQUIRED 3.125 MM
999
SPACER WASHER AS REQUIRED 3.100 MM
999
SPACER WASHER AS REQUIRED 3.075 MM
999
SPACER WASHER AS REQUIRED 3.050 MM
999
SPACER WASHER AS REQUIRED 3.025 MM
999
SPACER WASHER AS REQUIRED 3.000 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.975 MM
999
SPACER WASHER AS REQUIRED 2.950 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
NUT , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
NUT , Replaced By: A0029909251
999
SPACER WASHER AS REQUIRED 3.39 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.38 MM
999
SPACER WASHER AS REQUIRED 3.37 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.36 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.34 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.33 MM
999
SPACER WASHER AS REQUIRED 3.32 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.31 MM
999
SPACER WASHER AS REQUIRED 3.29 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.28 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.27 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.26 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.24 MM
999
SPACER WASHER AS REQUIRED 3.23 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.22 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.21 MM
999
SPACER WASHER AS REQUIRED 3.19 MM
999
SPACER WASHER AS REQUIRED 3.18 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.17 MM
999
SPACER WASHER AS REQUIRED 3.16 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.14 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.13 MM
999
SPACER WASHER AS REQUIRED 3.12 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.11 MM
999
SPACER WASHER AS REQUIRED 3.09 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.08 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.07 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.06 MM
999
SPACER WASHER AS REQUIRED 3.04 MM
999
SPACER WASHER AS REQUIRED 3.03 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.02 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.01 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.99 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.98 MM
999
SPACER WASHER AS REQUIRED 2.97 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.96 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.94 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.93 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.92 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.91 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SEAL RING
