Поз.
Артикул
Описание
8
AIR CLEANER , Replaced By: A3450947802
8
AIR CLEANER , Replaced By: A3450948002
8
AIR CLEANERFRAM DO BRASIL
8
AIR CLEANER"MANN DO BRASIL", 030-041 FROM IDENT NO.: 679208
16
FILTER ELEMENTTO 376 090 82 04
16
FILTER ELEMENT
24
NUT
32
GASKETTO 000 094 11 68,345 094 71 68
40
BRACKET
40
GASKET , Replaced By: A0000941027
40
BRACKETTO 345 094 78 02,345 094 79 02,77 02
40
BRACKETTO 345 094 78 02,345 094 79 02,77 02
48
GASKETTO 345 094 78 02
56
ADAPTER FITTINGTO 345 094 78 02,345 094 79 02
56
ADAPTER FITTINGTO 345 094 78 02,345 094 79 02
64
THREADED NIPPLETO 345 094 78 02,345 094 79 02
64
THREADED NIPPLETO 345 094 78 02,345 094 79 02
72
CYCLONE PRE-FILTER BOWLTO 345 094 77 02,345 094 78 02
72
CYCLONE PRE-FILTER BOWLTO 345 094 77 02,345 094 78 02
72
FILTER BOWLTO 376 090 96 01CICLONIZADOR
80
SCOOPTO 345 094 77 02
80
BOTTOM PARTITION
88
COVERTO 345 094 71 02,345 094 80 02
96
FILTER BOWLTO 345 094 80 02,81 02,85 02
96
FILTER BOWLTO 345 094 78 02,345 094 79 02
104
FASTENERTO 376 090 96 01
112
VALVETO 376 090 96 01
112
SEPARATORTO 374 094 00 02
120
NUT
120
NUT
120
NUT
128
SCREW CABLE CONNECTOR TO BRACKET
128
SCREW
128
SCREW
136
VACUUM BOXTO 345 094 78 02,345 094 79 02
136
VACUUM BOXTO 345 094 78 02,345 094 79 02
136
VACUUM BOXTO 345 094 80 02,78 02,81 02
144
NUTTO 345 094 79 02,345 094 77 02
144
NUTTO 345 094 79 02,345 094 77 02
152
LOCKTO 345 094 78 02,308 094 76 02
160
NUTTO 345 094 81 02,80 02,85 02
168
SEAL RINGTO 345 094 78 02,345 094 79 02
176
THREADED UNIONTO 345 094 81 02,80 02,85 02
184
NUTTO 345 094 78 02,345 094 79 02
192
BRACKET , 352.00/1,353,358 FROM CHASSIS 676465 ALSO INSTALLED ON 500001-599999,TYP 360 FROM CHASSIS 676465
200
SCREW BRACKET TO FRONT PANEL, 032,033,040,041,132,133,140,141 FROM CAB 1500001
208
LOCK WASHER RAIL TO BATTERY SUPPORT
216
SCREW BRACKET TO SIDE MEMBER
224
WASHER GROUND CABLE
232
LOCK WASHER , Replaced By: N912004010102
240
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
248
FILTER BOWLTO 376 090 96 01CICLONIZADOR
256
LOOM TIE. CLAMP
256
LOOM TIE. CLAMP
256
LOOM TIE. CLAMP AS REQUIRED
256
LOOM TIE. CLAMP AS REQUIRED
268
HOSE FROM PICO AIR CLEANER TO TURBOCHARGER
272
CLAMP
272
CLAMP
272
CLAMP. LOOM TIE90-110
272
CLAMP. LOOM TIE90-110
280
INTAKE PIPE
288
BRACKET
288
BRACKET AIR CLEANER
296
CLAMP
296
CLAMP. LOOM TIE90-110
304
HOSE , Replaced By: A3450947182
304
HOSE FROM PICO AIR CLEANER TO TURBOCHARGER
312
AIR INTAKE PIPE TURBOCHARGER
320
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
328
LOCK WASHER RAIL TO BATTERY SUPPORT
336
HOSE , FOR TURBINATE VEHICLESFB248085
336
HOSE TURBOCHARGER
344
LOOM TIE. CLAMP
344
LOOM TIE. CLAMP AS REQUIRED
999
PIPE ELBOW , Replaced By: A3455207206
