Поз.
Артикул
Описание
5
AIR CLEANER
5
AIR CLEANER
14
FILTER ELEMENT
17
SEPARATOR
20
GASKET AIR CLEANER BOWL TO 015 094 83 02
26
NUT
32
FILTER BOWL
35
DUST COLLECTOR BOWL
38
SCOOP
56
FASTENER
59
FASTENER AIR CLEANER BOWL MANN & HUMMEL
62
MAINTENANCE INDICATOR
65
GASKET
68
WASHER FELT
71
SCREW FUEL LINE TO BRACKET
74
SPRING WASHER PROTECTIVE PLATE TO BELL HOUSING
74
SPRING WASHER LICENSE PLATE TO BRACKET
77
RUBBER MOUNTING AIR CLEANER TO SUBSTRUCTURE
77
RUBBER MOUNTINGM10X50X20
80
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
80
NUT , Replaced By: N913023010002
83
WASHER EXHAUST MUFFLER TO STRAP
83
WASHER TRAILER PLUG SOCKET TO BRACKET
104
AIR INTAKE PIPE FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE
119
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
119
CLAMP FROM PICO AIR CLEANER TO INTAKE MANIFOLD AT ENGINE
122
HOSE
