Поз.
Артикул
Описание
262
BRACKET HELPER SPRING
268
HELPER SPRING SPRING STOP TO FRAME BOTTOM SIDE
274
SCREW PROPELLER SHAFT BEARING TO CROSS MEMBER
280
HEXAGON NUT
280
NUT , Replaced By: N910113010002
364
PLATE FRONT SPRINGS TO FRONT AXLE
364
PLATE , Replaced By: A6203310026
394
SHIM FRONT SPRINGS TO FRONT AXLE I
394
SHIM FRONT SPRINGS TO FRONT AXLE I 35 MM
412
SHIM FRONT SPRING, TO BE ADAPTED DURING ASSEMBLY
412
SHIM FRONT SPRING, TO BE ADAPTED DURING ASSEMBLY
412
SHIM , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3853210484
418
RUBBER BUFFER SPRING STOP
424
PLATE SHOCK ABSORBER MOUNTING,RIGHT TOP
424
PLATE SHOCK ABSORBER MOUNTING,LEFT TOP
430
BRACKET RIGHT
430
BRACKET LEFT
436
BUSHING LINE MOUNTING
442
SCREW FRONT AXLE REGULATING SOLENOID VALVE
442
SCREW , Replaced By: N000933008134
448
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
448
NUT , Replaced By: N913004008001
454
SCREW CONSOLE TO SIDE MEMBER
460
WASHER
466
LOCK WASHER FITTING TO BRACKET
472
BRACKET FRONT AXLE I SHOCK ABSORBER,TOP
478
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
484
WASHER
490
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
490
NUT , Replaced By: N910113012003
496
REINFORCEMENT RIGHT SHOCK ABSORBER
496
REINFORCEMENT LEFT SHOCK ABSORBER,4 336574
502
SCREW APPARATUS SUPPORT TO FRAME
502
SCREW , Replaced By: A9429901304
508
NUT STEERING SUPPORT TO FRAME
508
NUT , Replaced By: N910113014000
514
HEXAGON HEAD BOLT , Replaced By: A0029902704
514
SCREW , Replaced By: N308676012013
520
WASHER
526
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
526
NUT , Replaced By: N910113012003
532
BRACKET FRONT AXLE I SHOCK ABSORBER,RIGHT BOTTOM, TO BE ADAPTED DURING ASSEMBLY
532
BRACKET , Replaced By: A3913230640, +001A6993230050
532
BRACKET FRONT AXLE I SHOCK ABSORBER,LEFT BOTTOM, TO BE ADAPTED DURING ASSEMBLY
532
BRACKET , Replaced By: A3913230540, +001A6993230050
538
BUSHING SHOCK ABSORBER BRACKET
568
DOWEL PIN FRONT AXLE TO FRONT SPRINGS
574
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
574
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
574
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
574
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
586
NUT REAR SPRING TO REAR AXLE
586
NUT , Replaced By: N308674020000
586
NUT , Replaced By: N308673020002
592
SHOCK ABSORBER FRONT AXLE I BOGE
592
SHOCK ABSORBER FRONT AXLE I FICHTEL & SACHS
598
SPACER RINGTO 002 323 86 00,003 323 03 00,
604
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
616
SCREW SHOCK ABSORBER TO TOP BRACKET
622
NUT COMBINATION CYLINDER TO BEARING BRACKET
622
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
628
SCREW SHOCK ABSORBER TO TOP BRACKET
634
NUT COMBINATION CYLINDER TO BEARING BRACKET
634
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
