Поз.
Артикул
Описание
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
7
FITTING (PARTS KIT),LINE RUPTURE
9
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
256
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
259
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
330
BRACKET HOSDE TO FRAME
341
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
341
NUT , Replaced By: N913004008001
352
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
363
WASHER
374
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
385
BRACKET LEVER
387
VALVE (RELAY VALVE) WABCO
389
BRACKET RELAY VALVE TO CROSS MEMBER
391
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
391
NUT , Replaced By: N913004008001
393
SCREW PIPE CLAMP
393
SCREW , Replaced By: N304017008021
395
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
395
NUT , Replaced By: N913004008001
397
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
399
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
401
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
403
THRUST RING CHECK VALVE TO AIR RESERVOIR
403
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
405
O-RING CHECK VALVE TO AIR RESERVOIR
407
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
409
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
411
KNURLED HEAD SCREW PRESSURE SWITCH
413
NUT
418
METAL SPRING BELLOWS ,4 9579425 498312
429
BRACKET METAL SPRING BELLOWS
440
CONSOLE METAL SPRING BELLOWS
451
COVERING
462
COVERING INTERMEDIATE BEARING
473
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
484
WASHER BEARING BRACKET TO BRACKET
495
COTTER PIN CYLINDER TO BRACKET
506
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
506
SCREW , Replaced By: N308676012012
517
LOCK WASHER FITTING TO BRACKET
528
CYLINDER METAL SPRING BELLOWS,REAR AXLE I
539
SEAL RING
539
SEAL RING , Replaced By: A0239975247
550
BOOT
561
PIN WIRE CABLE TO LEVER
572
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
572
SPRING WASHER , Replaced By: N000137008212
583
WASHER EXHAUST MUFFLER TO STRAP
583
WASHER , Replaced By: N000125008443
594
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
605
WASHER BRACKET TO FENDER BRACKET
616
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
627
BRAKE HOSE FROM FITTING TO REAR AXLE ONE-CIRCUIT PISTON CYLINDER 450 MM
638
CLAMP HOSE TO FITTING
999
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
999
FITTING , Replaced By: A0029906171
999
BANJO UNION , Replaced By: N915052009009
