Поз.
Артикул
Описание
3
PLASTIC PIPE RISING PIPE 4X6 MM
3
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
6
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
9
UNION NUT
12
GLAND , Replaced By: A0019901667
12
SEAL CONE
15
SLEEVE LEAK LINE
18
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
21
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
27
LOOM TIE LINE MOUNTING 280 MM
30
FITTING 3/2-WAY VALVE,CONNECTION: "30"
33
HOLLOW SCREW LINE CONNECTION
33
HOLLOW SCREW LINE CONNECTION
36
SEAL RING PNEUMATIC VALVE
36
SEAL RING , Replaced By: N007603010110
39
HOLLOW SCREW HEATING CONNECTION
42
SEAL RING LINE CONNECTION
104
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
104
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
104
GROMMET FUEL LINE THRU FRAME SIDE MEMBER 38/30 MM
104
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
104
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
144
BRACKET BATTERY CABLE MOUNTING
144
BRACKET BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
146
CLAMPING PIECE BATTERY CABLE MOUNTING
148
SCREW DISTRIBUTOR TO CAB
148
SCREW DISTRIBUTOR TO CAB
152
NUT PUMP TO BRACKET
152
NUT PUMP TO BRACKET
152
NUT , Replaced By: N913004006001
154
SWITCH (BATTERY MASTER SWITCH)
155
CYLINDER
156
KNOB BATTERY MASTER SWITCH ACTUATION
160
SCREW BRACKET TO CROSS CONNECTION STRUT
160
SCREW REDUCTION VALVE TO BRACKET
160
SCREW , Replaced By: A0079900801
160
SCREW , Replaced By: N000933008301
160
SCREW BRACKET TO CROSS CONNECTION STRUT
160
SCREW , Replaced By: N304017008034
162
WASHER EXHAUST MUFFLER TO STRAP
162
WASHER , Replaced By: N000125008443
164
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
166
BRACKET BATTERY MASTER SWITCH
168
SCREW END PIECE TO EXHAUST PIPE M 10X25
168
SCREW END PIECE TO EXHAUST PIPE M 10X25
170
NUT STRAP TO BRACKET
170
NUT , Replaced By: N910113010000
172
VALVE BATTERY MASTER SWITCH ACTUATION
174
CURRENT LIMITER TACHOGRAPH,5 584018
174
CURRENT LIMITER , Replaced By: A0015455434
174
CURRENT LIMITER , Replaced By: A0025450334
176
SCREW FUSE TO BATTERY MASTER SWITCH AM 4X30
178
LOCK WASHER T-FITTING TO BRACKET
180
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
EMERGENCY LANTERN
999
EDGE GUARD SECTION , ORDER BY THE METER
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 24X1,5 129167
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 24X1,5 129167
999
CABLE CONNECTOR , Replaced By: A0015465441, +001A0009872844
999
PLUG CONNECTION POINT BEHIND REAR AXLE
999
PLUG REAR CABLE CONNECTOR,5 180266
999
BRACKET CABLE CONNECTOR
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1, M 24X1
999
BRACKET ELECTRIC CABLE MOUNTING
999
BRACKET FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BELL HOUSING
999
LOCK INSULATING HOSE
999
CONNECTOR BATTERY CABLE CONNECTOR
999
NEG. CABLE , Replaced By: A6205401831
999
CLAMPING PIECE , Replaced By: A3635460044
999
CAP CABLE CONNECTOR TO 6205400074, NOT USED
999
GROMMET LINE MOUNTING 50/45 MM
999
BRACKET LINES TO ENGINE
999
BRACKET BATTERY CABLE TO CROSS MEMBER
999
BRACKET BATTERY CABLE TO CROSS MEMBER
999
BRACKET FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BELL HOUSING
999
CLAMP BATTERY CABLE TO FRAME SIDE MEMBER NEAR TRANSMISSION
