Поз.
Артикул
Описание
5
HOSE FROM RADIATOR TO THERMOSTAT
5
HOSE FROM RADIATOR TO THERMOSTAT
8
CLAMP HOSE 70-90X13 MM
8
CLAMP , Replaced By: N000000000674
11
HOSE FROM RADIATOR OUTLET TO WATER PUMP
14
PIPE ELBOW AT WATER PUMP,5 510518
14
PIPE ELBOW AT WATER PUMP,5 1935955 510517
14
PIPE ELBOW , Replaced By: A6555010756
15
PIPE ELBOW FOR SCREW FITTING
17
SCREW BRACKET TO FRAME SIDE MEMBER
18
PIN PIPE ELBOW TO BRACKET,K 023462
19
SPACER RING PIPE ELBOW TO BRACKET,K 023462
20
NUT STRAP TO BRACKET
20
NUT , Replaced By: N910113010000
23
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
26
CLAMP HOSE 70-90X13 MM
26
CLAMP , Replaced By: N000000000674
29
CONNECTOR FOR SCREW FITTING
32
GASKET CONNECTOR
32
GASKET , Replaced By: A4422010480
32
GASKET CONNECTOR, Replaced By: A0002011080
32
GASKET CONNECTOR, Replaced By: A0002011180
32
GASKET CONNECTOR, Replaced By: A0002011280
35
SCREW END PIECE TO EXHAUST PIPE M 10X25
35
SCREW STRAP TO BRACKET
38
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
41
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
47
INTERMEDIATE PIECE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE,K 003769
47
INTERMEDIATE PIECE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
50
SCREW BRACKET ON LOAD SENSOR
53
NUT PUMP TO BRACKET
53
NUT , Replaced By: N913004006001
56
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6555013382
56
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
59
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR,K 121579
59
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
62
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
62
CLAMP
62
CLAMP , Replaced By: N000000000670
62
CLAMP , Replaced By: N000000000667
65
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
65
BREATHER PIPE ENGINE BREATHING
68
GASKET. SEAL DE-AERATION PIPE TO ENGINE
71
SCREW END PIECE TO EXHAUST PIPE M 10X25
86
HOSE DE-AERATION PIPE TO EXPANSION TANK
95
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
95
CLAMP HOSE TO FITTING AND TO OIL TANK
999
WASHER , Replaced By: A1894660751
