Поз.
Артикул
Описание
4
EXHAUST PIPE FRONT,FRONT PART
8
EXHAUST PIPE , Replaced By: A6694901119
8
EXHAUST PIPE FRONT,FRONT PART
12
EXHAUST PIPE FRONT,REAR PART
16
EXHAUST PIPE FRONT,REAR PART
20
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
24
VALVE PARTS KIT,K 181318N 817421 - N 825202
28
BUSHING THROTTLE VALVE SHAFT
32
LEVER EXHAUST-BRAKE THROTTLE VALVE
32
LEVER , Replaced By: A3661400232, +001N913017006000, +001N914126006025
36
BALL PIVOT BOTTOM B13X5 MM
40
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
40
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
40
SCREW , Replaced By: N000000001479
44
NUT , Replaced By: N913023006001
44
NUT SPRING-LOADED PUSH ROD
44
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
48
CYLINDER INTERMEDIATE SPEED STOP
48
CYLINDER
48
CYLINDER , Replaced By: A0004304926
48
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
52
BUSHING , Replaced By: A0004340850
52
BUSHINGTO 000 430 30 26/32 26
52
BUSHING"WABCO"
56
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
56
REPAIR KITTO 000 430 48 26,KNORR
60
NUT
60
NUT , Replaced By: N304035008001
64
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
64
BALL SOCKET
68
SECURING CLIP. CIRCLIP
72
PIN , Replaced By: A4421440574
72
PIN INTERMEDIATE SPEED STOP
72
PIN CYLINDER TO BRACKET
76
WASHER EXHAUST MUFFLER TO STRAP
80
NUT STRAP TO BRACKET
84
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
84
WASHER INTERMEDIATE SPEED STOP
88
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
92
BRACKET SHIFTING CYLINDER
92
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 077169/N 817421 - 825202, Replaced By: A3661440440
92
BRACKET POWER CYLINDER, TO BE ADAPTED DURING ASSEMBLY
96
SCREW BRACKET TO THROTTLE HOUSING M 8X16
100
SCREW
104
NUT CONNECTOR TO EXHAUST MANIFOLD
999
CYLINDER , Replaced By: A0004303026
999
CYLINDER
