Поз.
Артикул
Описание
10
CABLE INTERMEDIATE BEARING TO CONTROL SHAFT
15
BALL SOCKET
20
SECURING CLIP. CIRCLIP
25
YOKE SHIFTING ROD TO INTERMEDIATE LEVER
30
NUT
35
PIN WIRE CABLE TO LEVER
40
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
40
SPRING WASHER , Replaced By: N000137008212
45
WASHER BRACKET TO CROSS MEMBER
50
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
50
COTTER PIN LEVER TO ROD
55
BRACKET IDLING ADJUSTMENT
60
BRACKET IDLING ADJUSTMENT
65
SCREW REAR EXHAUST PIPE TO MUFFLER
70
BRACKET CLAMP
75
SCREW DISTRIBUTOR TO CAB
75
SCREW , Replaced By: N000933006151
80
WASHER , Replaced By: N009021006208
80
WASHER COMPRESSED AIR LINE TO BRACKET
85
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
85
WASHER COMPRESSED AIR LINE TO BRACKET
90
NUT , Replaced By: N913004006001
90
NUT PUMP TO BRACKET
95
CLAMP SENSOR CABLE TO FRONT AXLE
100
SCREW PUMP TO BRACKET
100
SCREW , Replaced By: N304017006016
105
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
105
WASHER COMPRESSED AIR LINE TO BRACKET
110
NUT BALL PIVOT TO LEVER
999
ROD (CONTROL ROD),FROM INTERMEDIATE BEARING TO ENGINE,5 4232975 573246
999
ROD (CONTROL ROD),FROM INTERMEDIATE BEARING TO ENGINE
999
ROD (CONTROL ROD),FROM INTERMEDIATE BEARING TO ENGINE,5 4232975 573246
