Поз.
Артикул
Описание
5
RESERVOIR EXPANSION TANK
8
LOCKING CAP
11
SEAL RING
14
STRAINER
17
CAP RESERVOIR DE-AERATION
20
RIVET RESERVOIR TO FIRE WALL
23
MASTER CYLINDER CLUTCH
23
MASTER CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0012955306, +001A6732900439
23
MASTER CYLINDER , Replaced By: A0012959706
26
BOOT
29
PLUG
29
PLUG , Replaced By: A0009971186
32
REPAIR KIT ,5 366603, Replaced By: A0002900512, +001A6732900439
32
CYLINDER. REPAIR KIT CLUTCH MASTER CYLINDER,5 366604
35
SCREW COVER PLATE TO BRACKET
38
ROD CLUTCH MASTER CYLINDER,5 366604
38
ROD CLUTCH MASTER CYLINDER,5 366603
41
BUSHING PISTON ROD TO CLUTCH PEDAL
44
SCREW FITTING TO TRANSMISSION M8X32
47
PIPE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER,K 032903
47
PIPE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER,K 032902
47
PIPE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER,K 032903
47
PIPE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER,K 032902
53
SLAVE CYLINDER CLUTCH ACTUATION
62
BOOT
65
VALVE CLUTCH SLAVE CYLINDER
65
BLEEDER VALVE , Replaced By: A0004310265
65
VALVE , Replaced By: A3075530107
68
PROTECTIVE CAP , Replaced By: A0004217187
68
PROTECTIVE CAP , Replaced By: A0004210887
68
PROTECTIVE CAP ,5 962906
74
REPAIR KIT CLUTCH SLAVE CYLINDER
77
FLANGE CLUTCH SLAVE CYLINDER TO BELL HOUSING
86
SCREW RADIATOR M 10X45
86
SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING M 10X170
89
BRACKET CLUTCH LINE,5 937103
92
SCREW REAR EXHAUST PIPE TO MUFFLER
92
SCREW , Replaced By: N304017008018
92
SCREW SUPPORT TO FENDER
95
WASHER , Replaced By: N000125008443
95
WASHER , Replaced By: N000125010532
95
WASHER EXHAUST MUFFLER TO STRAP
95
WASHER RADIATOR TO RUBBER MOUNTING
98
NUT STRAP TO BRACKET
98
NUT , Replaced By: N910113010000
101
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6732950340
101
BRACKET CLUTCH LINE
104
SCREW BRACKET TO SUPPORT M 16X20
104
SCREW , Replaced By: N304017016011
104
SCREWM 16X25
107
LOCK WASHERROCKINGER TYP 59 G140,59 G150
110
CLAMP LINE MOUNTING
110
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
113
SCREW PUMP TO BRACKET
113
SCREW , Replaced By: N304017006016
116
NUT , Replaced By: N913004006001
116
NUT PUMP TO BRACKET
119
LOOM TIE LINE MOUNTING 280 MM
999
BRACKET BRACKET ON SUPPORT,ENTRANCE,RIGHT
999
WASHER , Replaced By: N006902011100
999
SPACER WASHER BRACKET TO FRAME
999
BRACKET CLUTCH LINE
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017006016
999
SCREW , Replaced By: N000933016082
999
SCREW BRACKET TO ENGINE
999
WASHER , Replaced By: N006902011102
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
999
SCREW CLAMP TO BRACKET
999
SCREW LICENSE PLATE TO BRACKET
999
NUT , Replaced By: N913004006001
999
NUT , Replaced By: N913004008001
999
NUT , Replaced By: N910113010000
999
CLAMP ,K 147121, Replaced By: N000000000319
999
CLAMP PIPE ON FAN SHROUD
