Поз.
Артикул
Описание
164
REAR EXHAUST PIPE FRONT PART,5 337342 TO BE ADAPTED DURING ASSEMBLY
164
REAR EXHAUST PIPE FRONT PART,5 337343
167
REAR EXHAUST PIPE REAR PART,5 337343
167
REAR EXHAUST PIPE REAR PART,5 337342
185
CLAMP , Replaced By: N071555094502
185
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
188
SCREW END PIECE TO EXHAUST PIPE M 10X25
191
NUT STRAP TO BRACKET
191
NUT , Replaced By: N910113010000
194
BRACKET CENTRAL EXHAUST PIPE TO LEFT SIDE MEMBER
197
SCREW BRACKET TO SIDE MEMBER
197
SCREW , Replaced By: N304017010002
203
NUT , Replaced By: N910113010000
203
NUT STRAP TO BRACKET
206
SUPPORT REAR EXHAUST MUFFLER
209
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
212
NUT , Replaced By: N910113010000
212
NUT STRAP TO BRACKET
215
BRACKET RUBBER BUFFER,5 129244
215
BRACKET REAR EXHAUST PIPE TO BRACKET
218
SCREW , Replaced By: N304017010002
218
SCREW BRACKET TO SIDE MEMBER
221
NUT , Replaced By: N910113010000
221
NUT STRAP TO BRACKET
224
DAMPING PAD PARTICLE FILTER
227
RUBBER BUFFER BRACKET TO SUPPORT
227
RUBBER BUFFER BRACKET TO SUPPORT
230
BRACKET , Replaced By: A6205240340
230
BRACKET FUEL LINES TO TRANSMISSION
230
BRACKET FUEL LINES TO TRANSMISSION
233
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
233
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
236
SCREW BRACKET TO SIDE MEMBER
236
SCREW BRACKET TO SIDE MEMBER
236
SCREW , Replaced By: N304017010002
239
NUT STRAP TO BRACKET
239
NUT STRAP TO BRACKET
239
NUT , Replaced By: N910113010000
251
SCREW , Replaced By: A0099900101
251
SCREW , Replaced By: N000933008337
251
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
254
WASHER BRACKET TO LEFT SIDE MEMBER
254
WASHER , Replaced By: N009021008213
257
NUT , Replaced By: N913004008001
999
SUPPORT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 478323, Replaced By: A6734901434
999
SUPPORT EXHAUST MUFFLER TO BRACKET
999
BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. K 139807, Replaced By: A6744924841
999
BRACKET EXHAUST MUFFLER TO BRACKET
