Поз.
Артикул
Описание
14
17
VALVE QUICK-RELEASE VALVE
23
ELBOW FITTING
23
ELBOW FITTING
26
FITTING AT AIR RESERVOIR
29
CONNECTOR ON AIR DRIER
32
FITTING HOSE TO VALVE 3/8 NPTFM X 1/2 T
35
PART NAME MISSING SCREW
38
WASHER VALVE TO BRACKET 5/16-.640
41
PART NAME MISSING NUT
44
VALVE (HAND BRAKE VALVE)
45
BRACKET HAND BRAKE VALVE
46
PART NAME MISSING SCREW
46
SCREW5/16-18
47
SCREW CABLE MOUNTING 1/4-20
50
WASHER HAND BRAKE VALVE 1/4
50
PART NAME MISSING , Replaced By: A6889900040
53
PART NAME MISSING NUT
56
ELBOW FITTING
59
FITTING3/8 NPT
59
FITTING HAND BRAKE VALVE
62
WASHER
62
LOCK WASHER HAND BRAKE VALVE
65
NUT HAND BRAKE VALVE
68
ELBOW FITTING , TO BE ORDERED ONLY FROM MBMEX
71
SENDER UNIT66 PSI(4.55BAR) 1/8 - 27 NPT
74
FITTING , TO BE ORDERED ONLY FROM MBMEX
80
ELBOW FITTING
339
PLUG REGENERATION TANK BR 0,6MPT
341
NUT1-14
343
WASHER
345
FITTING3/8 NPT
347
ELBOW FITTING
999
VALVE (QUICK-RELEASE VALVE) GTD 223455
999
VALVE (QUICK-RELEASE VALVE) BW 5008333
999
FITTING3/8 NPT
999
NUT1-14
999
WASHER VALVE TO BRACKET 5/16-.640
999
WASHER
999
ELBOW FITTING
999
FITTING1/4 X 1/4
999
ELBOW FITTING90GR. 1/2NPTFX5/8T
