Поз.
Артикул
Описание
10
BEARING BRACKET PEDAL BEARING BRACKET
10
BEARING BRACKET
10
PEDAL BEARING BRACKET PEDAL BEARING BRACKET
10
BEARING BRACKET PEDAL BEARING BRACKET
10
PEDAL BEARING BRACKET EXCHANGEABLE TOGETHER ONLY WITH: A 461 290 21 18 BEI / BY CODE US7
10
BEARING BRACKET , Replaced By: A4632940301, +001A4602940092, +002N000125008418, +002N000933008147, +002N913004008004
90
PLUG
90
PLUG AIR INTAKE PIPE
90
PLUG
95
BRACKET TO PEDAL ASSEMBLY
96
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
97
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
100
PEDAL , Replaced By: A4632904101
100
BRAKE PEDAL
100
BRAKE PEDAL EXCHANGEABLE TOGETHER ONLY WITH: A 461 294 07 01 BEI / BY CODE US7
100
PEDAL (BRAKE PEDAL)
110
PEDAL (BRAKE PEDAL)
130
BUSHING , Replaced By: A1242920050
140
PAD BRAKE PEDAL
160
SPINDLE
160
SPINDLE
160
SPINDLE BRAKE PEDAL
170
GROOVED PIN AT BEARING BRACKET
180
SPRING , Replaced By: A1079930410
180
SPRING
185
WASHER PUMP TO CONSOLE
190
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
195
PEDAL HINGE PIN BRAKE BOOSTER ASSEMBLY TO PEDAL, X 19620920111222
195
PIN LEVER TO ROD
197
COTTER PIN LEVER TO ROD
205
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
205
SCREW SUPPORT TO FENDER
205
SCREW PIPE CLAMP
205
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
205
SCREW PEDAL ASSEMBLY TO FIRE WALL M8 X 25
205
SCREW REAR AXLE REGULATING SOLENOID VALVE
205
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
210
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
220
NUT
230
BRACKET , Replaced By: A0009884683
240
BLIND RIVET BRACKET MOUNTING A4,8X12
250
FOOTREST CLUTCH PEDAL
255
HEXALOBULAR BOLT. SCREW STEP TO ENTRANCE
260
COVER PLATE PEDAL BRACKET
260
COVER PLATE BEARING BRACKET
270
SCREW CLAMP TO BRACKET AND TO PIPE
280
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
290
NUT
300
PLUG AIR INTAKE PIPE
320
STOP SCREW , Replaced By: A2019880211
325
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
330
NUT SPRING-LOADED PUSH ROD
340
WASHER COMPRESSED AIR LINE TO BRACKET
350
BRAKE LIGHT SWITCH STOP LIGHT, Replaced By: A0015459509
360
BRACKET STOP LIGHT SWITCH
370
NUT HOOK TO BRACKET
900
PIN BUSHING HOUSING FUSE AND RELAY BOX,DRIVER,4-POLE
900
PLUG HOUSING WIPER MOTOR ON REAR WALL 3-PIN JPT
901
PIN BUSHING HOUSING WARNING DEVICE
