Поз.
Артикул
Описание
5
SUPPORT FAN
8
GROOVED BALL BEARING
8
GROOVED BALL BEARING , Replaced By: A0009804415
8
GROOVED BALL BEARING , Replaced By: A0009804415
11
LOCK RING TORSION BAR TO LINK,5 903513
14
SCREW BRAKE BOOSTER ASSEMBLY TO APPARATUS SUPPORT M 10X40,4 338291
14
SCREW CROSS MEMBER TO FRAME
14
SCREW FENDER TO BRACKET, NOT USED
17
PULLEY FAN
20
LEVER BELT TIGHTENER
23
SHAFT BELT TIGHTENER
26
LOCK RINGTO 001 431 37 05,4 375193
29
PULLEY TIGHTENER PULLEY
32
SCREW BELT TENSION READJUSTMENT, 362 842770 364 012804 EXCEPT FOR 012768,012771,021773,012776,012779-012785 366 048719
35
PULLEY CRANKSHAFT
38
SCREW CABLE HARNESS MOUNTING
41
NUT
44
INTERMEDIATE PIECE PULLEY TO VIBRATION ABSORBER
47
SCREW CABLE HARNESS MOUNTING
47
SCREW BRACKET TO BUMBER STRUT
50
CLAMPING BOLT
53
BUSHING
56
SCREW , Replaced By: N304017010050
56
SCREW , Replaced By: N304017010055
59
NUT BRACKET TO SUPPORT AND TO END PIECE
62
CLAMPING PIECE TIGHTENER PULLEY
62
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
62
CLAMPING PIECE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3141550228
65
NUT TIGHTENER PULLEY TO LEVER
68
NUT R.H. THREAD
71
SCREW BRACKET TO TRANSMISSION
74
V-BELT FROM TIGHTENER PULLEY TO FAN DRIVE 12X1250 MM,D 180260
999
INTERMEDIATE PIECE , Replaced By: A4220350314, +006N000933008247
999
BELT TIGHTENER , Replaced By: A4222060133, +001A4032001302, +002N000472038000
