Поз.
Артикул
Описание
26
DRIVE
26
DRIVE
28
HOUSING
30
SHAFT P.T.O., 401-403 083703 404 000682
30
SHAFT P.T.O., 401-403 083703 404 000682
38
SPACER TUBE P.T.O.
41
BEARING RING P.T.O.
44
CYLINDR. ROLLER BEARING P.T.O.
45
CYLINDR. ROLLER BEARING P.T.O.
46
ANG. CONTACT BALL BEARING P.T.O.
51
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1.0 MM
51
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1.8 MM
51
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1,6 MM
51
FITTED WASHER AS REQUIRED 1.4 MM
51
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1,2 MM
59
SEAL RING
65
SEAL RING FLANGE TO P.T.O.
67
FLANGE P.T.O., 401-403 083703 404 000682
71
SEAL RING HUB TO P.T.O. SHAFT
77
FLANGE OUTPUT FLANGE TO P.T.O. SHAFT
78
GEAR (DRIVE GEAR),P.T.O.
81
NUT DRIVE GEAR TO P.T.O. SHAFT
81
NUT DRIVE GEAR TO P.T.O. SHAFT
81
NUT DRIVE GEAR TO P.T.O. SHAFT, FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 572715, Replaced By: A0009904453
83
NUT FLANGE TO MAIN SHAFT, UP TO IDENT NO. 207851 FROM IDENT NO. 207852 SEE MOCROFICHE, MODEL 712.0
87
SCREW CONNECTOR TO CYLINDER HEAD M 8X25
87
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
90
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
91
SEAL RING
91
SEAL RING P.T.O. TO TRANSMISSION
