Поз.
Артикул
Описание
5
FUEL TANK
8
FUEL STRAINER
11
SEAL RING
17
STRAP FUEL TANK MOUNTING, 059608(WHC: WDB) 904079(WHC: VAG)
17
STRAP , Replaced By: A4634700340
20
SHIM RIGHT
20
SHIM LEFT
23
WASHER EXHAUST MUFFLER TO STRAP
23
WASHER , Replaced By: N000125008443
26
NUT BRACKET TO BATTERY/APPARATUS SUPPORT,5 579088
29
COVERING BELOW FUEL TANK
32
BRACKET
35
SCREW COVER PLATE TO COVER PLATE M 6 X 10
35
SCREW , Replaced By: N304017006034
38
WASHER , Replaced By: N009021006208
38
WASHER COMPRESSED AIR LINE TO BRACKET
40
SCREW COVER PLATE TO BRACKET
42
WASHER COMPRESSED AIR LINE TO BRACKET
42
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
44
PLASTIC SECTION AT COVERING
46
FILLER NECK
48
FUNNEL , Replaced By: A1694700029
50
FUEL STRAINER , Replaced By: A4634700206
53
GROMMET FILLER NECK THRU FENDER RECESS
56
SCREW PUMP TO BRACKET
56
SCREW , Replaced By: N304017006016
59
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
59
WASHER COMPRESSED AIR LINE TO BRACKET
62
HOSE FROM FILLER PIPE TO FUEL TANK
62
EXTENSION BETWEEN FUEL TANK AND FILLER NECK
65
CLAMP , Replaced By: N000000000672
65
CLAMP HOSE FASTENING 50-70X13 MM
68
CLAMP HOSE TO RETARDER 60-80X13 MM
68
CLAMP , Replaced By: N000000000673
71
FILLER CAP. FUEL FILLER CAP MAKE HUF, STATE LOCK NUMBER WHEN ORDERING
71
FILLER CAP , WITH LOCK UNDEFINED
71
FILLER CAP , Replaced By: A0004700730
71
FILLER CAP *** FA.HUF, STATE LOCK NUMBER WHEN ORDERING
74
SEAL RING
77
GUIDE SIGN REFUELLING PLATE, IN GERMAN
77
GUIDE SIGN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 658987 F 932311, Replaced By: A1245849517
78
GUIDE SIGN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 658987 F 932311, Replaced By: A1245849617
78
GUIDE SIGN REFUELLING PLATE, IN GERMAN
78
GUIDE SIGN REFUELLING PLATE, IN GERMAN, ONLY APPLICABLE TO VEHICLES EQUIPPED WITH CATALYTIC CONVERTER
80
SENDER UNIT FUEL TANK
80
SENDER UNITTO A 461 470 01 04
80
SENDER UNIT FUEL TANK
83
GASKET , Replaced By: A0009975149
83
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
83
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
86
HOSE LEAK LINE, ORDER BY THE METER
86
HOSE FUEL HOSE TO FUEL PUMP 120 MM, ORDER BY THE METER
89
CYLINDRICAL PIN DIFFERENTIAL LOCK
92
CLAMP CHECK VALVE,K 169122
