Поз.
Артикул
Описание
4
ENGINE SUPPORT REAR LEFT, UP TO IDENT NO.: 4 939097 FROM IDENT NO.: SEE SA 32 409/1
8
ENGINE SUPPORT REAR LEFT, UP TO IDENT NO.: 4 939097 FROM IDENT NO.: SEE SA 32 409/2
12
ENGINE SUPPORT REAR LEFT
16
ENGINE SUPPORT LEFT REAR
20
ENGINE SUPPORT REAR LEFT
26
ENGINE SUPPORT REAR RIGHT, UP TO IDENT NO.: 4 939097 FROM IDENT NO.: SEE SA 32 409/1
26
ENGINE SUPPORT REAR RIGHT, UP TO IDENT NO.: 4 939097 FROM IDENT NO.: SEE SA 32 409/2
26
ENGINE SUPPORT REAR RIGHT
26
ENGINE SUPPORT RIGHT REAR
26
ENGINE SUPPORT REAR RIGHT
46
RUBBER MOUNTING , Replaced By: A6452400318
46
RUBBER MOUNTING
46
RUBBER MOUNTING , Replaced By: A6452400518
46
RUBBER MOUNTING
46
RUBBER MOUNTING , Replaced By: A6452400418
46
RUBBER MOUNTING
58
SUPPORT REAR RUBBER MOUNTING, TO BE ADAPTED DURING ASSEMBLY
74
SCREW BRACKET TO SIDE MEMBER
74
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
74
SCREW , Replaced By: N308676014020
81
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
81
WASHER , Replaced By: N000125015019
86
SCREENING PLATE
92
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 18X60
92
SCREW , Replaced By: N308676018010
92
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X60
92
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
97
SCREW VIBRATION ABSORBER TO CONSOLE
104
WASHER ENGINE MOUNTING TO SUPPORTING ARM
110
SCREW , Replaced By: N308676016007
110
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
110
SCREW , Replaced By: N308676016006
110
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
110
SCREW , Replaced By: N308676016004
110
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
999
WASHER CONSOLE TO FRAME
999
SUPPORTING ARM BELL HOUSING,4 753306
999
SUPPORTING ARM REAR
999
ENGINE SUPPORT LEFT REAR,4 743986
999
ENGINE SUPPORT RIGHT REAR,4 743986
999
ENGINE SUPPORT , Replaced By: A6552423101
999
ENGINE SUPPORT , Replaced By: A6552423201
999
ENGINE SUPPORT LEFT REAR
999
ENGINE SUPPORT RIGHT REAR
999
SHIM REAR RUBBER MOUNTING TO CONSOLE
999
SHIM SUPPORT TO TRANSMISSION
999
RUBBER MOUNTING REAR
