Поз.
Артикул
Описание
89
BRACKET COMPRESSED AIR LINE TO INTAKE MANIFOLD, LEFT FRONT
113
SCREW BRACKET TO ENGINE
116
WASHER , Replaced By: N007349008007
116
WASHER
122
LOOM TIE BRAKE LINE MOUNTING
134
LOOM TIE LINE MOUNTING 280 MM
134
LOOM TIE LINE MOUNTING
140
CLAMP LINE MOUNTING
140
CLAMP LINE MOUNTING
143
SCREW , Replaced By: N304017006016
143
SCREW PUMP TO BRACKET
146
NUT OIL TANK TO BRACKET
146
NUT , Replaced By: N913002006009
152
VALVE (3/2-WAY SOLENOID VALVE) EKS
153
PROTECTIVE CAPWABCO
154
SEAL RINGWABCO
154
SEAL RINGBOSCH
155
SEAL RINGBOSCH
156
GASKET KITKNORR
157
SCREW VALVE TO BRACKET
157
SCREW VALVE TO BRACKET, Replaced By: N304014008002
159
NUT , Replaced By: N913004008001
159
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
159
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
161
BRACKET 3/2-WAY SOLENOID VALVE
161
BRACKET 3/2-WAY SOLENOID VALVE
163
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
163
SCREW , Replaced By: N304017008016
164
WASHER EXHAUST MUFFLER TO STRAP
164
WASHER , Replaced By: N000125008443
165
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
167
HOLLOW SCREW HEATING CONNECTION
170
SEAL RING LINE CONNECTION
171
SCREW TO PLUG THE FREE CONNECTIONS
173
SEAL RINGBOSCH
176
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
179
SCREW TWO-WAY VALVE TO BRACKET
185
NUT TWO-WAY VALVE TO BRACKET
200
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
203
HOLLOW SCREW FUEL LINE TO FEED PUMP
203
HOLLOW SCREW , Replaced By: N915036010108
206
SEAL RING FUEL LINE TO FEED PUMP
209
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL BOSCH
209
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL WABCO
212
REPAIR KIT 3/2-WAY VALVE WABCO
212
REPAIR KIT 3/2-WAY VALVE BOSCH
215
SPRING WASHER AT CAB FLOOR
218
NUT SUCTION LINE TO OIL PUMP
221
SCREW. UNION SCREW , Replaced By: A0009973734
221
SCREW. UNION SCREW LINE CONNECTION
224
BREATHER , Replaced By: A3933280065
224
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
230
SCREW PLUG , Replaced By: N000908012009
230
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
233
SEAL RING LINE CONNECTION
236
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
239
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
239
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
242
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
999
SHIM 3/2-WAY SOLENOID VALVE
