Поз.
Артикул
Описание
5
FUEL LINE15X1.5, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
8
FUEL LINE8X1, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
24
RIGHT-ANGLE PLUG
26
PLUG CONNECTION
28
PLUG CONNECTION , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.02.2010
104
VALVE
106
VALVE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.01.2012
106
SHUT-OFF VALVE , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.02.2012
108
NON-RETURN VALVE8X1, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.02.2010
606
NUT BRACKET TO FIRE WALL
606
NUT HORN TO BRACKET M8
706
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
706
SCREW GGVS-COMPONENT IN BATTERY CARRIER M6 X 55
706
SCREW BATTERY CABLE TO BRACKET M6X45
706
SCREW BRACKET AND CLAMP M6X20
708
SCREW PIPE ELBOW TO BRACKET M8X12
708
HEXAGON HEAD BOLT. SCREW BRACKET MOUNTING M8 X 30
708
SCREW , Replaced By: N910143008000
708
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
708
SCREW BRACKET TO CAB REAR PANEL M 8X20
820
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
900
LOOM TIE
900
CABLE TIE IONIC EXCHANGER 380X7.8MM
