Поз.
Артикул
Описание
90
EDGE GUARD SECTION WITHOUT BRUSH
92
EDGE GUARD SECTION WITH BRUSH
94
SHEET METAL SCREW BRACKET TO SUPPORT
96
PANELLING A-PILLAR,LEFT
98
PANELLING A-PILLAR,RIGHT
99
COVERING TOP LEFT
99
COVERING TOP LEFT
100
COVERING TOP RIGHT
100
COVERING TOP RIGHT
103
GRILLE
103
GRILLE ENGINE AIR INTAKE
103
GRILLE ENGINE AIR INTAKE
103
GRILLE ENGINE AIR INTAKE
106
SCREEN VENTILATION DRIVER'S WINDOW
112
COVERING
112
COVERING VENTILATION GRILLE TO BODY
112
COVERING VENTILATION GRILLE TO BODY
120
RIVETED NUT LINE MOUNTING M 6X60
126
RUBBER SEAL , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
132
ADHESIVE TAPE4.5X10 MM, ORDER BY THE METER
140
LOCK FUEL LINE
144
SHEET METAL SCREW
410
ADHESIVE TAPE , TO BE ADAPTED DURING ASSEMBLY
