Поз.
Артикул
Описание
440
PIPE LINE
440
PIPE LINE
442
PIPE SOCKET
443
FLANGE
443
FLANGE THREADED D36MM
444
FLANGE NOT THREADED D36MM
445
PIPE SOCKET
446
FITTING
447
FITTING
449
SHUT-OFF VALVENW25
449
VALVE , Replaced By: A0048305884
590
PIPE LINE
592
PIPE SOCKET
593
FLANGE
594
FLANGE NOT THREADED D36MM
595
PIPE SOCKET
597
FITTING
599
SHUT-OFF VALVENW35
599
VALVE , Replaced By: A0048305984
600
NUT BRACKET TO FIRE WALL
605
SCREW BRACKET AND CLAMP M6X20
630
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
655
HEXAGON HEAD BOLTM6X80
660
HEXAGON HEAD BOLTM6X60
665
HEXAGON HEAD BOLT. SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
705
MOUNTING CLAMP28/15
705
CLAMP28/15, Replaced By: A0019951842
705
CLAMP CABLE HARNESS MOUNTING
725
CLAMP35/20, Replaced By: N000000007514
725
CLAMP COOLING WATER HOSES
725
CLAMP35/20
818
TRAY
820
LOCK
822
BRACKET
824
TRAY
826
PLATE30MM
865
GASKET34X42 MM
870
RUBBER MOUNTING MOUNTING FOR PRESSURE AND RETURN LINE 28MM
880
RUBBER MOUNTING
900
VALVE. FILLING VALVE ON SUCTION SIDE
900
FILLING VALVE ON DELIVERY SIDE
903
CAPTO A 000 832 02 84
903
CAPTO A 000 832 03 84
905
OIL-BREAK SWITCH ON DELIVERY SIDE
905
OIL-BREAK SWITCH ON SUCTION SIDE 0,4 BAR
910
SEALING STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
CABLE TIE LINE MOUNTING 375X8.4MM
999
ADHESIVE TAPE3X50MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
